Your unit should be serviced annually
by an authorised service person.
PG36D Gas Log Fireplace
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult
an authorised installer, service agency or
the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
fl ammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-554
Models: PG36D-NG
PG36D-LPG
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any
appliance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas
supplier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
02/16/06
Advertisement
Table of Contents
Related Manuals for Regency PG36D-NG
Summary of Contents for Regency PG36D-NG
- Page 1 Owners & Installation PG36D Gas Log Fireplace Models: PG36D-NG PG36D-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, alteration, What to do if you smell gas: service or maintenance can cause injury or Do not try to light any property damage.
-
Page 2: To The New Owner
As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions ® and the many features of your Regency Fireplace. ®... -
Page 3: Table Of Contents
Warranty ..............39 Optional Brick Panels ..........22 Log Set Installation ............22 Standard Flush Door ...........24 Wiring ................25 Remote Control ............26 Operating Instructions ..........26 Lighting Instructions ............26 Resetting The Unit ............26 Shutdown Instructions ..........26 First Fire ..............26 ® Regency PG36D Gas Log Fireplace... -
Page 4: Data Badge
DATA BADGE The label is located on the front inside base of the DATA BADGE NOTE: Regency ® units are This is a copy of the label that accompanies each unit, visible when the bottom louvre is open. constantly being improved. Check the label on PG36D Gas Fireplace. -
Page 5: Installation
GENERAL SAFETY INSTALLATION SAVE THESE INSTRUCTIONS INFORMATION CHECKLIST The PG36D-NG or PG36D-LPG Room Sealed 1) The appliance shall be installed in 1) Locate appliance Fireplace must be installed in accordance with accordance with the manufacturer's a) Locate Your Gas Fireplace AS5601-2004 and NZS 5261 5261 and these installation instructions,local gas fi... -
Page 6: Clearances
" E x t e r i o r F l u e Te r m i n a t i o n ( 153m m ) ( 153m m ) Locations." Diagram 1 ® Regency PG36D Gas Log Fireplace... - Page 7 INSTALLATION ® Regency PG36D Gas Log Fireplace...
-
Page 8: Combustible Mantels
3 in section "Combustible Mantels" and Diagram 1 in section "Locating Your Gas Fireplace." BARCELONA INSTALLATION NOTE: Framing Dimensions When installing the PG36D with the ® Barcelona Trim into a Regency Style 3 36-1/4" 37-1/4" 17-3/8" 46-1/2"* Mantel Kit, ensure that the combustible... -
Page 9: Unit Assembly Prior To Installation
2) Use the same screw hole position for the Side Nailing Strips as was used for the Top Facing Support. Attach each side nailing strip using 3 screws. ® Regency PG36D Gas Log Fireplace... -
Page 10: Exterior Flue Termination Locations
(IV) A fl ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free fl ow of air at the appliance is achieved. ® Regency PG36D Gas Log Fireplace... -
Page 11: Flueing
Flex installations. ® 3) If you are installing the PG36D into a Regency Mantel Kit, use the minimum horizontal vent height (centre-line of 1029mm). Remember to include the mantel base in your calculations and to maintain the 32mm clearance (38mm with Flex) to the underside of the mantel top. -
Page 12: Simpson Dura-Vent Flueing
229mm + 229mm 108mm - 146mm 152mm + 229mm Simpson Dura-Vent Co-Axial Flue GS SIMPSON DURA-VENT FLUEING COMPONENTS LIST All Simpson Dura-Vent components are available directly from Regency ® Part # Description Part # Description Part # Description Horiz. Termination Kit includes: 90 902B 48"... -
Page 13: Flueing Arrangements - Horizontal Terminations
6-7/8" (175mm) outer diameter A fl ue guard should be used whenever the termination is lower than the specifi ed minimum or as per local codes. Note: Regency ® Co Axial Flue System (Flex) is only approved for horizontal terminations. -
Page 14: Flueing Arrangements - Horizontal Terminations
INSTALLATION FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS SIMPSON DURA-VENT DIRECT FLUE GS SYSTEM and REGENCY ® CO AXIAL FLUE SYSTEM (FLEX) (LPG & NG) The diagram below shows examples of horizontal termination arrangements using two 90 elbows (two 45 elbows equal one 90 elbow). -
Page 15: Flueing Arrangements - Vertical Terminations
Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles. Note: Must use optional rigid pipe adaptor when using Simpson Dura-Vent pipe (Part # 510-994). ® Regency PG36D Gas Log Fireplace... - Page 16 • Flue must be supported at offsets • Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles as listed in section "Clearances." Diagram 3 ® Regency PG36D Gas Log Fireplace...
-
Page 17: Horizontal Terminations
Diagram 5 fl ue pipe to the fl ue termination, slide the to outer pipe on every Wall Thimble (Part # 620-926) over the fl ue twist-lock joint. pipe. ® Regency PG36D Gas Log Fireplace... -
Page 18: Vertical Terminations
fl oor or ceiling of every level. To install the Firestop spacer in a fl at ceiling or wall, cut a 10 inch square hole. Frame the hole Diagram 5 as shown in Diagram 3 and install the fi restop. ® Regency PG36D Gas Log Fireplace... -
Page 19: Conversion Kit For Ng To Lpg Model #516-969
17) Replace the yellow "NG" label with the red "LPG" label. 18) Disconnect the 6 pin Molex connector and carefully pull out the control box. Rear Log Burner Tray NOTE: The control box is held in place with velcro. ® Regency PG36D Gas Log Fireplace... - Page 20 Put back the modulator plastic cap. WARNING: To ensure the correct operation of the modulator it is necessary that the plastic cap (A) is returned to its original location. ® Regency PG36D Gas Log Fireplace...
-
Page 21: Gas Line Installation
INSTALLATION GAS LINE GAS PIPE PRESSURE PG36D-NG System Data INSTALLATION TESTING For 0 to 4500 feet altitude Burner Inlet Orifi ce Sizes: #37( 2.65mm) The appliance must be isolated from the gas The gas line can be brought through either the supply piping system by closing its individual right or the left side of the appliance. -
Page 22: Optional Brick Panels
- do not force into position. 2) Sprinkle the vermiculite all over the top of the base brick panel. 3) Place the Log 02-75 on the rear log support pins with the fl at side to the back. 02-75 ® Regency PG36D Gas Log Fireplace... - Page 23 6) Position Log 02-54 across the cutouts in Logs 02-51 and 02-53. The notch in the bottom right end fi tting against the 5th grate 02-51 tab. 02-54 Place embers in these 3 locations on the burner tray. Log indentation ® Regency PG36D Gas Log Fireplace...
-
Page 24: Standard Flush Door
Repeat for 2nd spring. the door towards the unit, diagram 1. on the unit. Diagram 2. diagram 3. Diagram 3 Diagram 2 To remove the fl ush door, reverse the above Diagram 1 steps. ® Regency PG36D Gas Log Fireplace... -
Page 25: Wiring
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from ® Regency PG36D Gas Log Fireplace... -
Page 26: Remote Control
INSTALLATION REMOTE CONTROL LIGHTING FIRST FIRE INSTRUCTIONS Use the Regency ® Remote Control Kit approved The FIRST FIRE in your heater is part of the for this unit. Use of other systems may void paint curing process. To ensure that the paint 1) Plug the power cord into a power outlet. -
Page 27: Operating Instructions
Listed below are some examples. All are normal operating sounds and should not be considered NOTE: If you have an incorrect fl ame pattern, as defects in your appliance. contact your Regency ® dealer for further SUMMARY OF instructions. -
Page 28: Copy Of The Lighting Plate Instructions
Turn off all electric power to the unit if service is to be performed. DO NOT REMOVE THIS INSTRUCTION PLATE 918-332a WARNING: DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IN OPERATION. ® Regency PG36D Gas Log Fireplace... -
Page 29: Maintenance
NOT BE PLACED ON OR NEAR heat resistant paint (not with wall paint). THE APPLIANCE. Regency ® uses StoveBright Paint - Metallic 4) Inspect joints, to verify that no pipe Black #6309. -
Page 30: Gold Or Brass Louvres & Trim
5/8" fl at glass gasket for the Bay Front (Part # 936-243) and a tadpole glass gasket for the Flush Front (Part # 936-155). DOOR GLASS Your Regency ® fi replace is supplied with high temperature, 5 mm Neoceram ceramic glass that will withstand the highest heat that your unit will produce. -
Page 31: Removing Valve Tray
13) To replace the burner tray assembly reverse these instructions. 8) Remove the 10 Philips screws which secure the valve tray 14) Check for any gas leaks. assembly. 15) Check for proper fl ame appearance and glow on logs. ® Regency PG36D Gas Log Fireplace... -
Page 32: Fan Replacement
Connector Ground Wire 9) Pull out the fan. 5) Remove the electric cover by undoing the 2 screws, pull out the grommet and the harness. 10) Reverse steps to install new fan. Electric Cover ® Regency PG36D Gas Log Fireplace... -
Page 33: Parts List
910-912 Ignition Module to Valve Cable 910-906 Reset Switch 910-083 Ignition Module (1) 910-916 Ignition Module (2) 910-514 Jumper * Note: The Control Box Cable wires for the FG38 come separately: 910-502, 910-505, 910-506, 910-507, 910-509 ® Regency PG36D Gas Log Fireplace... -
Page 34: Main Assembly
Brick Panel Set - Herringbone Brown 513-904 Brick Panel Set - Herringbone Red 33) * Brick Panel - Back 34) * Brick Panel - Left 35) * Brick Panel - Right 511-031 Brick Clip (each) 918-554 Manual ® Regency PG36D Gas Log Fireplace... -
Page 35: Burner Assembly & Log Set
Middle Right Log 94) * Front Left Log 95) * Center Left Log 96) * Center Right Log 97) * Front Bottom Log 98) * Middle Left Log *Not available as a replacement part. ® Regency PG36D Gas Log Fireplace... -
Page 36: Bay Front Assembly
Bay Front Trim (Set) - Gold 120) * Glass Retainer Bracket 113) * Bay Front Trim-Gold-Bottom 121) 780-932 Bay Front Screen 114) * Bay Front Trim-Gold-Top ® 160) 948-216 Regency Logo Plate *Not available as a replacement part. ® Regency PG36D Gas Log Fireplace... -
Page 37: Flush Front Assembly
138) * Flush Louver Assy-Top 159) * Finishing Trim Right 139) * Flush Louver Assy-Btm ® 161) 948-216 Regency Logo Plate 146) * Barcelona Assy - Black *Not available as a replacement part. 148) * Barcelona Louver Assy-Black 510-934 Flush Glass Trim (Set) - Brass... - Page 38 NOTES ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ® Regency PG36D Gas Log Fireplace...
-
Page 39: Warranty
The warranty does not extend to any part or parts which show evidence of misuse or abuse, neglect, accident, lack of maintenance, or improper installation. ® Products made by other manufacturers and used in conjunction with the operation of this appliance without authorization from Regency , may nullify your warranty on this product. - Page 40 Printed in Canada © Copyright 2006, FPI Fireplace Products International Ltd. All rights reserved.
