installation
|
19
Levelling Bolt Installation
1. Use a 9/16" wrench to adjust the front leveling bolts located on the right and left side of the firebox.
Note: The leveling bolts add 3/4" (19 mm) to the overall height when adjusted all the way down = 25-3/4" (654 mm).
2. Remove the bottom refractory panels, then the side panels to gain access to the rear levelling bolts. You can adjust them using a 9/16" (14 mm) wrench
or socket.
Andiron Installation
Install the andirons by sliding them on top of the pins located at the front of the unit.
|
19
Regency i3000A/i3000R
