P33 Gas Fireplace
P33 Zero Clearance Direct Vent Gas Fireplace
P33 WITH THE FLUSH OR BAY FRONT
Model
Fuel Type
Minimum Supply Pressure
5" W.C. (1.25 kPa)
Manifold Pressure - High
3.8" W.C. (0.95 kPa)
Manifold Pressure - Low
1.1" W.C. (0.27 kPa)
#44 DMS - 0-2000ft
Orifi ce Size
#45 DMS - 2000-4500ft
Minimum Input
Altitude 0-2000 ft. (0-610m)
Minimum Input
Altitude 2000-4500 ft. (610-1372m)
Maximum Input
Altitude 0-2000 ft. (0-610m)
Maximum Input
Altitude 2000-4500 ft. (610-1372m)
Vent Sizing
4" Inner / 6 5/8" Outer
Approved Venting Systems
Flex Vent Systems:
FPI AstroCap™ Flex Vent
Rigid Pipe Vent Systems:
Simpson Direct Vent Pro®
American Metal Products® Amerivent Direct
Security Secure Vent®
Selkirk Direct-Temp™
Metal-Fab® Sure Seal
A
Unit Dimensions
Description
A
Front Face Width
B
Rear Firebox Width
C
Front Face Height
D
Height w/ Standoff
E
Unit Depth
F
Firebox Height
Framing Dimensions
Description
G
Framing Width
***
***
H
Framing Height
Vertical
Framing
I
Depth
Horizontal
J
Corner Wall Length
K
Corner Facing Wall Width
L
Framed Chase Ceiling
M
Vent Centerline Height
***
Important: Framing height requires consideration of the hearth
depth. Dimension H = H + the thickness of installed hearth.
28
P33-NG4
P33-LP4
Natural Gas
Propane
12" W.C. (3.00 kPa)
11" W.C. (2.74 kPa)
3.3" W.C. (0.82 kPa)
#54 DMS
12,500 BTU/h
(3.66 kW)
10,500 BTU/h
(3.07 kW)
10,500 BTU/h
(3.07 kW)
22,500 BTU/h
(6.59 kW)
21,500 BTU/h
(6.30 kW)
21,000 BTU/h
(6.15 kW)
4" Inner / 6 5/8" Outer
B
A
C
D
F
E
P33
33" (838mm)
23" (584mm)
29" (737mm)
31 1/2" (800mm)
12-3/4" (324mm)
28 1/2" (724mm)
P33
33-1/4" (845mm)
***
31-3/4" (806mm)
19 1/2" (495mm) Vertical Rise
16 1/2" (419mm) Rigid
12-3/4" (324mm) Flex
37 1/2" (953mm)
53-1/4" (1353mm)
36" (914mm) Rigid
32" (813mm) Flex
30" (762mm) Rigid
26" (660mm) Flex
Gas Fireplaces
H
G
K
Dimension
Description
N
Gas Connection Height
O
Gas Connection Inset
P
Gas Connection Width
Q
Minimum Framing Depth
Maximum Framing Depth
R
(including wall thickness)
Please refer to Exterior Vent Terminations for
additional guidelines on vent locations.
August 2008 Product Specifi cations Book
L
Top Header
Drywall
(or other
facing)
10" (254mm)
dia. Hole through
wall Vent.
I
M
Q
J
R
N
O P
Opening for gas
connection
P33
1 1/2" (38mm)
4" (102mm)
3" (76mm)
16 1/2" (419mm) Rigid / 12-3/4" (324mm) Flex
40 1/2" (419mm) Rigid / 36-3/4" (324mm) Flex
