Data Type
Data
Apply to
Cancel
Apply
II-1-3-4 Inter-LAN Routing
Up to 25 routing profiles provided by the router allow the users to divide groups into different
subnets. In addition, different subnets can link for each other by configuring Inter-LAN Routing.
To add/edit a profile, click the +Add/Edit link to get the following page.
Choose the type (ASCII or Hex or Address List) for the data to be
stored.
Enter the data in the Data field based on the data type selected.
ASCII Character - A text string. Example: /path.
Hexadecimal Digital - A hexadecimal string. Valid characters are from
0 to 9 and from a to f. Example: 2f70617468.
Address List - One or more IPv4 addresses, delimited by commas.
Select LAN interface(s) to which this entry is applicable.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
64
