Draytek Vigor C410 Series User Manual page 31

For Physical Type with Ethernet
Click the Edit link of WAN1 or WAN2
Available settings are explained as follows:
Item
Advanced
Mode:ON/OFF
Index
Profile Name
Enabled
Physical Type
Bind to Physical
Interface
Setup Mode
to open the following page.
Description
Click to show or hide the advanced settings (IP Alias and WAN MAC
Address) for the WAN interface.
Displays current WAN interface.
Displays the name of the profile.
Switch the toggle to enable or disable the function.
General Setup
Displays the physical type used by this interface.
Select a physical interface (Ethernet).
Determine the WAN connection established on the settings page or
automatically based on the AutoHunt profiles, processed one by one.
Manual – If selected, the WAN connection will be performed
according to the settings configured in this page.
AutoHunt – The Vigor router will automatically connect to Ethernet
WAN connection. Once connected and powered on, the router will run
through a list of network connection settings (based on the autohunt
profiles) to determine if it can establish a connection. If it is unable to
connect, the mechanism will proceed to the next ISP setting until it
receives an IP address.
If Auto Hunt is selected, configure the following:
AutoHunt Profile – Select the AutoHunt profile(s).
+Add – Click to specify the autohunt profile(s).
21
