Draytek Vigor C410 Series User Manual page 39

Physical Type
Bind to Physical
Interface
Peer SSID
Channel
Security Mode
WPA Algorithm
Password
IPv4 Connection Type
Mode
General Setup
Displays the physical type used by this interface.
At present, only Wireless 2.4GHz is available for WAN3 and Wireless
5GHz for WAN4.
Enter the identification of the wireless device.
Select the channel of frequency of the device.
There are several modes provided for you to choose from. Each mode
will bring up different parameters (e.g., Pass Phrase) for you to
configure.
WPA3 Personal – The Router connects to the wireless AP as a WPA3
client and the encryption key should be entered in PSK.
WPA2 Personal – The Router connects to the wireless AP as a WPA2
client and the encryption key should be entered in PSK.
OPEN – The encryption mechanism is turned off.
Select AES as the algorithm for WPA.
Enter 8~64 ASCII characters, such as 012345678..(or 64 Hexadecimal
digits leading by 0x, such as "0x321253abcde...").
IPv4
It is available when Both or IPv4 is selected as IP Version.
DHCP – The router receives IP configuration information from a DHCP
server.
WAN DNS - Select Auto or Manual.

If Manual is selected, specify the primary and secondary DNS
servers.
IPv4 Primary DNS - IP address of primary DNS server.
IPv4 Secondary DNS - IP address of secondary DNS server.
Static IP – Set the access mode as Static IP.
IP Address – WAN IP address assigned by the ISP.

Subnet Mask – WAN subnet mask.

Gateway IP – IP address of the WAN Gateway.

IPv4 Primary DNS – IP address of primary DNS server.

IPv4 Secondary DNS - IP address of secondary DNS server.

WAN Connection Detection
Configures how the WAN connection is monitored.
Always On - The router assumes the WAN connection is always active.
ARP Detect - The router broadcasts an ARP request every 5 seconds.
If no response is received within 30 seconds, the WAN connection is
deemed to have failed.
29
