I-1-4 LED Indicators and Connectors for Vigor C510ax
Before you use the Vigor modem, please get acquainted with the LED indicators and connectors
first.
LED
LED
Connectors
Interface
Status Explanation
Blinking The router is powered on and running normally.
Off The router is powered off.
On Internet connection is ready.
Blinking The data is transmitting.
Off Internet connection is not ready.
SIM card is inserted into the slot and detected by Vigor
On
device.
Blinking No SIM card in detected.
On Wireless access point is ready.
Blinking Ethernet packets are transmitting over wireless LAN.
When both ACT and WLAN LEDs blink quickly, it means
Blinking
the WPS function is enabled and active. The system is
(quickly)
waiting for a wireless station of connection.
Off The WLAN function is inactive.
On The LAN port is connected.
Blinking The data is transmitting.
Blinking The data is transmitting.
Explanation
Connecter for installing WLAN antennas. (For ax model).
