Draytek Vigor C410 Series User Manual page 255

IPsec Dial-In Protocol
Dial-In Allowed
Schedule
IPsec Dial-Out
Protocol
Remote IP/ Domain
Dial-Out Mode
Username
Password
Dial-Out Settings
Dial-in Allowed Schedule

IPsec (with the direction on Both, Dial-Out)-
IPsec Dial-Out Protocol

Remote IP/ Domain

Dial-Out Mode

Select a protocol to trigger an IPsec VPN connection through the
Internet.
IKEv1/v2

XAuth.

Connect and disconnect according to schedule profiles.
Always Allow – Select this option to maintain an always on dial-in
connection.
Scheduled –Select this option to make the VPN connection based on
the schedule.
Drop the Active Tunnel when Schedule is Enforced – Switch

the toggle to enable/disable the function.
VPN Schedule – Use the drop-down menu to specify one VPN

profile. Before configuring the VPN Schedule, add the required
time intervals in Configuration>> Objects>> Schedule.
Select a protocol to trigger an IPsec VPN connection through the
Internet.
IKEv1

IKEv2

IKEv2 EAP

XAuth

Enter IPv4 or hostname for the remote VPN server.
On Demand – The VPN connection will be triggered when detecting
traffic going to the remote network.
Always On – Select this option to maintain an always on dial-out
connection.
Scheduled –Select this option to make the VPN connection based on
the schedule.
Drop the Active Tunnel when Schedule is Enforced – Switch

the toggle to enable/disable the function.
VPN Schedule – Use the drop-down menu to specify one VPN

profile. Before configuring the VPN Schedule, add the required
time intervals in Configuration>> Objects>> Schedule.
Username and Password
It is available when XAuth is selected as IPsec Dial-In/Dial-Out
Protocol.
Used by the remote LAN to establish a VPN connection.
It is available when XAuth is selected as IPsec Dial-In/Dial-Out
Protocol.
Used by the remote LAN to establish a VPN connection.
IKE Authentication for Dial-Out/Both
It is available when Dial-Out is selected as the Direction and IPsec is
selected as VPN Type.
245
