Draytek Vigor C410 Series User Manual page 89

Hide SSID
WPA Algorithm
Key Renewal Interval
Default Key
Key # Type
Key #
Cancel
Apply
Switch the toggle to enable(hide) /disable (show) the SSID.
Select to keep SSIDs from showing up when scans are performed by
wireless clients, which makes it harder for unauthorized clients or
STAs to join your wireless LAN. Depending on the wireless client
and software used, the user may see only an AP listed without the
SSID, or the AP might not even show up.
WPA Settings
This feature is available for WPA3 Enterprise, WPA2 Enterprise,
WPA Enterprise, WPA3 Personal, WPA2 Personal, WPA Personal,
WPA3/WPA2 Personal, or WPA2/WPA Personal mode.
Select TKIP, AES, or TKIP/AES as the algorithm for WPA.
Note that not all modes of Vigor router support WPA3 mode.
However, if the Vigor router supports WPA3 Personal/Enterprise
security mode, the WPA algorithms will be set as AES.
It is available when WPA # is selected as Security.
WPA uses a shared key for authentication to the network. However,
normal network operations use a different encryption key that is
randomly generated. This randomly generated key is periodically
replaced. Enter the renewal security time (seconds) in the column.
Smaller interval leads to greater security but lower performance.
Default is 3600 seconds. Set 0 to disable re-key.
WEP Settings
This feature is available for WEP Personal mode.
Four keys can be entered here, but only one key can be selected at a
time. The format of WEP Key is restricted to 5 ASCII characters or 10
hexadecimal values in 64-bit encryption level, or restricted to 13
ASCII characters or 26 hexadecimal values in 128-bit encryption
level. The allowed content is the ASCII characters from 33(!) to
126(~) except '#' and ','.
Hex/ASCII - The format of WEP Key is restricted to 5 ASCII
characters or 10 hexadecimal values in 64-bit encryption level, or
restricted to 13 ASCII characters or 26 hexadecimal values in 128-bit
encryption level. The allowed content is the ASCII characters from
33(!) to 126(~) except '#' and ','.
Enter 5 ASCII characters or 10 hexadecimal values in 64-bit
encryption level, or 13 ASCII characters or 26 hexadecimal values in
128-bit encryption level.
Discard current settings and return to the previous page.
Save the current settings and exit the page.
79
