PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 1 C1
3 2 C9, C10
4 2 C2, C3
5 1 C4
6 3 C5, C6, C7
7 1 C8
8 1 D1
9 1 INPUT
10 2 L1, L2
11 2 OUTPUT+,
OUTPUT-
12 2 P1, P2
13 2 R1, R4
14 6 R6, R8, R10, R11,
R13, R14
15 4 R5, R7, R9, R12
16 1 R2
17 1 R3
18 1 U1
19 2 VIOC+, VIOC-
Note 1. These items are not stuffed (DNI).
DEMO MANUAL SCP-LT3463-EVALZ
PART DESCRIPTION
PRINTED CIRCUIT BOARD
CAP 4.7uF 25V CER X5R 0805
CAP MLCC 0603 (Note 1)
CAP 1uF 50V CER X7R 0805
CAP 0.1uF 100V CER X7R 0603
CAP MLCC 0805 (Note 1)
CAP 10pF 50V CER NP0 0805
DIODE SCHOTTKY BARRIER RECTIFIER
CONN MALE 3POS 2.54MM PITCH R/A
IND 10uH 0.45A 0.39-OHM
CONN FEMALE 3POS 2.54MM PITCH R/A
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY
STRAIGHT 2MM PITCH
RES 4.53M 1% THICK FILM 0805
RES THICK FILM 0805 (Note 1)
RES 0-OHM 1% THICK FILM 0805
RES 301K 1% THICK FILM 0805
RES 280K 1% THICK FILM 0805
IC DUAL MICROPOWER DC/DC CONVERTER WITH SCHOTTKY
DIODES
CONN FEMALE 2POS 2.54MM PITCH R/A
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_060170a
SAMSUNG CL21A475KAQNNNG
N/A
SAMSUNG CL21B105KBFNNNE
SAMSUNG CL10B104KC8NNNC
N/A
AVX 08055A100JAT2A
DIODES INC B0540W-7-F
SULLINS PBC03SBAN
MURATA LQH32CN100K53L
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
VISHAY CRCW08054M53FKEA
N/A
VISHAY CRCW08050000Z0EA
PANASONIC ERA-6AEB3013V
PANASONIC ERA-6AEB2803V
ANALOG DEVICES LT3463AEDD#PBF
SULLINS PPPC021LGBN-RC
