Analog Devices SCP-LT8362-I-EVALZ Demo Manual

DESCRIPTION
Demonstration circuit SCP-LT8362-I-EVALZ features the
LT8362 in a Cuk configuration. It operates with a switching
frequency of 2MHz and is designed to convert a 4.5V to
42V source to –15V, with up to 1A output current (depend-
ing on input voltage).
Like all boards in the Signal Chain Power series, this board
is designed to be easily plugged into other SCP boards to
form a complete signal chain power system, enabling fast
evaluation of low power signal chains. To evaluate this
board, some universal SCP hardware is required, namely:
SCP-INPUT-EVALZ
SCP-OUTPUT-EVALZ
SCP-1X5BKOUT-EVALZ
SCP-THRUBRD-EVALZ
Table 1. Performance Summary
SYMBOL PARAMETER
V Max Input Voltage
IN(MAX)
V Max Output Voltage
OUT(MAX)
I Switch Current Limit
SW(LIM)
BOARD PHOTO
DEMO MANUAL SCP-LT8362-I-EVALZ
LT8362 Low I
SCP-FILTER-EVALZ
SCP-1X2BKOUT-EVALZ
SCP-5X1-EVALZ
NOTES
Figure 1. Photo of SCP-LT8362-I-EVALZ
DEMO MANUAL
SCP-LT8362-I-EVALZ
Signal Chain Power
Inverting Regulator
Q
To properly evaluate SCP series demo boards, you will
need the SCP Configurator companion software. SCP
Configurator can help you choose the right board and to-
pology for your design.
Note that this Demo Manual does not cover details im-
portant to the operation and configuration regarding the
LT8362. Please refer to the
plete description of the part.
Design files for this circuit board are available.
All registered trademarks and trademarks are property of their respective owners.
LT8362 datasheet for a com-
MIN TYP MAX
48
–48
2
UNITS
V
V
A
Rev. 0
1
