Specifications - Ametek BrightTEK ST9 Series Operator's Manual

3.0

Specifications

ST95 Cellular Uplink Host / Uplink Client
Hardware
Hazardous Classification
Weight
Construction
Enclosure
Performance
Output Voltage
Output Current
Sensor
Battery
Expected Battery Life
Wireless Communications
Mode
Cellular Specifications
12
• Remember to follow the National Electric Code or other
local codes and the System Control Drawing in this
manual. If you are unfamiliar with these regulations con-
sult the appropriate personnel before installation.
• Insert the housing into the mounting bracket and tighten
the clamp around it.
2.10.1 Testing
• For ST95 Cellular Uplink Hosts, start up the unit with
the magnet. The green LED on the circuit card will begin
to flash. Examine the LED sequence and verify proper
communications with the BrightTEK Data Center. If a
red light is observed, an error has occurred. Contact
Customer Support for help.
• Allow the unit to complete the communications pro-
cess. This could take several minutes, and the LEDs
will go dark when the process is complete.
• Call BrightTEK Customer Support or access the
BrightTEK online portal to verify the tank level and the
initialization process has successfully completed.
• Verify the key calibration parameters are properly con-
figured via the Tank Data Online web portal.
• Verify the product level is properly configured via the
website.
• If technical support is required, please call BrightTEK
Customer Support at 1(630) 969-4000 or email
fieldservice.magnetrol@ametek.com.
Class 1 Div. 1 Group D, Temperature Code T3C
Without Sensor Assembly: 2.0 lbs. (0.91 kg)
ROHS Compliant
CPVC w/Lexan Cover, Weatherproof, NEMA 4X/IP56, UL94V-0
Nominally 21V ±5%
Rated from 0-50mA
Intrinsically Safe 4-20 mA
6V - SmartTank Battery Pack, P/N 394-00023
Up to three years depending on website settings
LTE Digital Wireless Radio / Satellite RF Approval: FCC Part 15 Approved
GPS Receiver: Internal Antenna, Optional External GSM Antenna
LTE Cat-1 with 3G fall back (Verizon is LTE only)
41-622 BrightTEK ST9x Operator Manual
™
