2.3

Initial Inspection

When you receive the ST95 Cellular Uplink Host and/
or Uplink Client, thoroughly inspect it for any damage
which may have occurred during shipping. If there is
any damage to the devices contact AMETEK LMS Cus-
tomer Support at 1 (630) 969-4000 as soon as possible
or email to fieldservice.magnetrol@ametek.com.
Locate the packing checklist in the shipping container.
Check for any missing items before you begin installa-
tion.
Tools Required for Installation:
• Phillips Screwdrivers
• • #0 Tip ( ⁄ " D), 21/2" large blade
1
8
• • #2 Tip (1/4"D), 4" large blade
• Adjustable slip-nut wrenches
• • 1"– 3" jaw cap × 101/4" or
• • Adjustable pliers 1"– 3" jaw cap (channel-lock type)
• Open end wrench (
WARNING: The ST95 Cellular Uplink is certified for Class 1
Division 1 Group D hazardous locations only
2.4

Wiring the ST95 to a Sensor

• The ST95 Uplink Client is designed to be installed
directly to specific sensor assemblies and equipment
that conforms to industry 4–20mA standards. When the
Uplink is connected to multiple devices the total loop
resistance must be calculated and understood. The
Uplink itself has a resistance of 350 ohms at 21 Volts.
Contact Customer Support for technical help with your
unique installation.
• Refer to the System Control drawing for a visual of
the installation. Before you begin, read all the steps
involved. Note that the picture in the drawing portrays a
Remote Mount Configuration. The equipment shown on
the left side does not pertain to the Uplink.
• When routing the cable down the side of a tank, secure
it using cable ties or other fasteners as required. Mount
the Uplink Housing at the chosen site within the 50-
foot range of the cable. See "Mounting the Electronics
Housing" on the following page.
• Refer to the System Control Drawing in this document.
The table at the end of the drawing identifies the colors
of the Uplink cable and their function.
⁄ ")
