2.5
Remote Universal Mounting Parts (all ST9x)
STYLE
1
SCREW MOUNT
Screw self
xxxxx/threading
STYLE
3
PIPE CLAMP
Spacer
Clamp, Hose
*Only one style of installation configuration can be built from this kit. For customer assembly & installation*
41-622 BrightTEK
ST9x Operator Manual
™
• Wire the Sensor positive and negative wires to the col-
• If using a second Sensor, wire the Sensor positive and
ST95 UPLINK CABLE TERMINATION
To Customer Sensor Using
Uplink Cable (Wire Color)
TOP VIEW
Hanger
SIDE VIEW
TOP VIEW
Nut & Screw
Hanger
SIDE VIEW
ors marked (CKT1, 21V+) and (CKT1, Input) respectively.
negative wires to the colors marked (CKT2, 21V+) and
(CKT2, Input) respectively.
Orange
Yellow
Black or Brown
White
Green
STYLE
2
Washer split
Clamp
STYLE
4
Extra hose clamp
to enlarge clamping
diameter
Magnet
4–20 Loop Function
Circuit 1, 21V+
Circuit 1, Input
Ground
Circuit 2, Input
Circuit 2, 21V+
CLAMP MOUNT
Screw
TOP VIEW
Hanger
Spacer
SIDE VIEW
MAG MOUNT
TOP VIEW
Nut & Screw
Hanger
SIDE VIEW
Spacer
7
