41-622 BrightTEK ST9x Operator Manual
™
Turn on the AP4 power. The ST95 Host callout will start.
That could take several minutes to initially power up the
ST95 Host and make that first callout.
• If the GREEN LED is not flashing after the AP4 powers
on, please refer to the troubleshooting section of the
Operators manual (AMETEK LMS bulletin 41-622.
• At the end of a callout attempt the ST95 Host flashes
the GREEN LED 3 times to indicate success. It turns on
the RED LED and flashes the GREEN LED to indicate
an error number. For 1–3 flashes, contact Customer
Support.
• Extended cable is available as an accessory.
7.4.4 ST95 Client Installation
If you are using the Host to communicate to Clients, it
is suggested to assign each Client to the Host before
installation in the tank.
Once this is done and you have tested the communica-
tions you may then mount each Client in the tank.
At this point you can choose your desired location for
the Host/AP4 for a test.
Follow the LED Description table to read the strength of
the WLAN signal or interpreting the lights.
Test the Host to see that it can communicate to all Cli-
ents from the location you chose.
You can start the Host magnetically.
Repeat the test again to ensure that communications
are stable.
CLIENT LED DESCRIPTION
A slow GREEN LED flashes as the Client starts up, the
GREEN LED and RED LED alternately flash indicating
Power ON
that the Client is attempting to contact a Host. The
Client attempts to find any Host on any WLAN channel
The RED LED turns off and the GREEN LED flashes to
indicate a Host was found. The Host will then report
Any Host found the Client to the Data Center. Allow three minutes
before starting the next Client to allow the Host to
complete the cell
The GREEN LED and RED LED continue to flash for
approximately 32 seconds and then the RED LED
No Host found
changes to steady on and the GREEN LED slowly
flashes six times to indicate no Host was found
Once the GREEN LED is blinking do not press the
button. If you do the unit will re-start its signal search.
You may need to press the button after the initial light
Note
sequence is finished. The button is loacted opposite
the battery connector. By pressing the button, the unit
will begin its search for a signal
Sequence applicable to units that have not been asso-
ciated with a host device via the portal.
25
