Installation Guide | In-back/Out-top Cooling Kit for FA11-FA12
The holes must match the holes in the outer flange of the back duct.
16X Ø 6 (0.2)
Figure 5: Vent Dimensions for Backplate in 600 mm (24 in) Cabinet
8
| Danfoss A/S © 2024.09
592 (23.3)
Installation
18 (0.7)
0.0
1383 (54.4)
4X 1394 (54.9)
1396 (55.0)
1590 (62.6)
4X 1592 (62.7)
1603 (63.1)
AN361429223580en-000201 / 136R0251
