Installation Guide | In-back/Out-top Cooling Kit for FA11-FA12
Figure 14: Installation of the Backplate and Back Duct
1
Backplate
3
M5 clip-on nut
5
M5x18 screw
7
8-hole gaskets
9
Rittal cabinet
Danfoss A/S © 2024.09
2
Mounting plate
4
Back duct
6
M6x12 screw
8
6-hole gaskets
10
Frequency converter
AN361429223580en-000201 / 136R0251 |
Installation
1
2
3
4
5
6
7
8
9
10
17
