Installation Guide | In-back/Out-top Cooling Kit for FA11-FA12
1
2
3
4
5
Figure 2: Overview of In-back/Out-top Cooling Kit
1
Frequency converter
3
Bottom gasket
5
Bottom cover
7
Top duct assembly
9
Back gasket
11
M6x12 screw
4
| Danfoss A/S © 2024.09
2
Rittal cabinet
4
M5x14 screw
6
M5 hex nut
8
Clip-on nut
10
Back duct
12
M5x18 screw
Installation
6
7
8
9
10
11
12
AN361429223580en-000201 / 136R0251
