Installation Guide | In-back/Out-top Cooling Kit for FA11-FA12
Creating a Vent Opening in the Mounting Plate
2.3
To create mounting holes and a back vent opening in the mounting plate, use the following steps. Use the dimensions in
600 mm (24 in) cabinets, or Figure 4
Procedure
1.
Drill 6 mounting holes in the back of the frequency converter using the dimensions in the template.
2. Insert 6 M10 pem self-clinching nuts (not supplied) in the mounting holes.
3.
Cut out the vent opening in the mounting plate using the dimensions in the template.
The opening must match the frequency converter vent opening.
4.
Drill 6 screw holes around the vent opening using the dimensions in the template.
The holes must match the holes in the inner flange of the back duct.
Danfoss A/S © 2024.09
for 800 mm (32 in) cabinets.
Installation
Figure 3
AN361429223580en-000201 / 136R0251 |
for
