Introduction
This section gives an overview of the DTP3 T 212 D and its features. Topics include:
• About this Guide
•
Product Description
• Features
•
Application Diagram
About this Guide
This user guide contains installation, operation, and configuration information for the DTP3 T 212 D.
NOTE: Throughout this guide, the general terms for "switcher," "transmitter," and "switching transmitter" are
used interchangeably to refer to the DTP3 T 212 D.
Product Description
The DTP3 T 212 D is a two-input, decorator-style, multi-format transmitter consisting of HDMI and USB-C inputs
as well as an analog audio input and a DTP/HDBaseT output. The transmitter supports resolutions up to
4096x2160 @ 60 Hz at 4:4:4 chroma sampling. It extends HDMI, USB-C/DisplayPort, bi-directional RS-232, and
remote power up to 330 feet (100 m). It offers many integration-friendly features such as EDID Minder,
auto-switching between inputs, and analog stereo audio embedding.
Features
•
Transmits USB‑C
The DTP3 T 212 D provides high reliability and maximum performance on an economical and easily installed
cable infrastructure.
• Supports computer and video resolutions up to 4K/60 @ 4:4:4 — Support of 4096x2160 at 60 Hz with
4:4:4 color sampling requires connection to matching DTP3 products.
•
Analog stereo audio embedding — Analog stereo audio signals can be selectively embedded onto the
digital video output signal and transported over DTP.
•
Auto‑switching between inputs — Allows for easy, unmanaged installation in locations such as in a lectern
or floor box.
•
Supported HDMI 2.0b specification features include data rates up to 18 Gbps, HDR, Deep Color up to
12‑bit, 3D, and HD lossless audio formats
• Remote power capability with DTP3 products — For streamlined installation, the transmitter can be
remotely powered by a DTP3-enabled product over the twisted pair connection. It can also be configured to
provide power to a connected DTP3 receiver.
•
Connects USB‑C sources that support DisplayPort Alt Mode
• Extron XTP DTP 22 shielded twisted pair cable is strongly recommended for optimal performance
•
Compatible with CAT 6A shielded twisted pair cable
• DTP3 output is compatible with HDBaseT
send video to an HDBaseT-enabled display.
• HDCP 2.3 compliant — Ensures display of content-protected 4K video media and maintains interoperability
with earlier versions of HDCP.
video, HDMI, audio, and control up to 330' (100 m) over a shielded CAT 6A cable —
®
‑enabled devices — The DTP3 output can be configured to
®
DTP3 T 212 D • Introduction 1
