TEMPORARY OPERATIONS
Menu Display Name Default
Htg Valve 0%
SCR Capacity 0%
F&BP Damper 0%
ModPrhtVlv 0%
ModPrhtDmpr 0%
PreheatVlv Off
Htg Stg 1 Off
Htg Stg 2 Off
Htg Stg 3 Off
Htg Stg 4 Off
MHGRht Valve 0%
RH Bleed Valve Off
LSCRht Valve 0%
ER Wheel Off
ER Whl CapCmd 0%
ERBP Dmpr Cl Off
ERBP Dmpr Op Off
SCR Preheat 0%
Alm Output Off
Aux Output Off
EconStatusOut Off
RelDmprCls Off
OM 1373-1
Range Description
0-100% Htg Valve is an adjustable item that manually sets the capacity of the hot water or steam
control valve .
0-100% SCR Capacity is an adjustable item that manually sets the capacity of the SCR electric
heater .
0-100% F&BP Damper is an adjustable item that manually sets the capacity of the Face and
Bypass Damper .
0-100% An adjustable item that manually controls the capacity of preheat hot water or steam
valve .
0-100% An adjustable item that manually controls the capacity of preheat damper.
Off An adjustable item that manually controls on/off of preheat hot water or steam valve.
On
Off Htg Stg 1 is an adjustable item that manually turns on stage 1 of heat in a staged heater.
On
Off Htg Stg 2 is an adjustable item that manually turns on stage 2 of heat in a staged heater.
On
Off Htg Stg 3 is an adjustable item that manually turns on stage 3 of heat in a staged heater.
On
Off Htg Stg 4 is an adjustable item that manually turns on stage 4 of heat in a staged heater.
On
0-100% MHGRht Valve is an adjustable item that manually sets the capacity of the modulating
hot gas reheat valve .
Off RH Bleed Valve is an adjustable item that manually sets the capacity of the modulating
hot gas reheat bleed valve .
On
0-100% LSCRht Valve is an adjustable item that manually sets the capacity of the modulating hot
gas reheat valve .
Off ER Wheel is an adjustable item that manually turns on the energy recovery wheel.
On
0-100% ER Whl CapCmd is an adjustable item that manually sets the capacity the energy
recovery wheel speed .
Off ERBP Dmpr Cl is an adjustable item that manually closes the Energy recovery wheel
bypass damper .
On
Off ERBP Dmpr Op is an adjustable item that manually opens the Energy recovery wheel
bypass damper .
On
0-100% SCR Preheat is an adjustable item that manually sets the capacity of the SCR Preheat
defrost coil .
Off Alm Output is an adjustable item that manually turns on the alarm output.
On
Off Aux Output is an adjustable item that manually turns on the Auxiliary output DO10.
On
Off An adjustable item that manually turn on/off economizer status output.
On
Off RelDampCls is an adjustable item that manually turns on the Relief Damper Close
output .
On
