Daikin MICROTECH 4 Operation Manual page 161

ADvANCED OPERATION
Configuration Description
Code Position
6 Damper Type
7 Heating Type
8,9,10 Max Heat Rise
OM 1373-1
Values
0=None
1=Single Position 0-30% (30OA)
2=Single Position 100% (100OA)
3=Modulating Economizer Air side (Econ)
4= Modulating Economizer Air side with
FDD (EconFDD)
5=Single Position 100% with Recirc
(100wRec)
0=None
1=F&BP Control (F&BP)
2=Steam or Hot Water (HW_Stm)
3=Modulated Gas, 5-1 (M1G5-1) (was
L200)
4=Modulated Gas, 5-1 (M1G5-1) (was
L400)
5=Modulated Gas, 5-1 (M1G5-1) (was
L600)
6=Modulated Gas, 10-1 (M1G10-1) (was
H400)
7=Modulated Gas, 10-1 (M1G10-1) (was
H600)
8=Modulated Gas, 10-1 (M2G10-1) (was
L800)
9=Modulated Gas, 10-1 (M3G10-1) (was
L1200)
A=Modulated Gas, 20-1 (M2G20-1) (was
H800)
B=Modulated Gas, 20-1 (M3G20-1) (was
H1200)
C=2 Stage Electric (2StgE)
D=2 Stage Gas (2StgG)
E=4 Stage Electric (4StgE)
F=4 Stage Gas (4StgG)
G=SCR Electric (SCR)
H=SCR Electric/Supplemental Reheat
(SCRSRht)
I=Not Used
J=Modulating Gas, 20-1 (M4G10-1)
K= Modulating Gas, 40-1 (M4G20-1)
L=Modulating Gas, 12-1 (M1G12-1)
Three Digits (Default = 100, Range 0-100)
Notes
161
