OTHER CONFIgURATIONS
Table 39: Main Menu \ Commission Unit \ Sensr1:RmZn1, 2, or 3
Menu Display Default
Name
Sensor1 Name RoomZn1
Rem Space T -
Rem Space CO2 -
Rem Space RH -
Rem Space Spt -
Rem Occupancy -
Snsr1 ID -
Sensor 1 Addr -
Snsr1 Alm Sts -
Sensor1 Cmd -
Sensor1 State -
OM 1373-1
Range
*******
(7 character name)
-0 .0-150°F
0-5000ppm
0-100%
50 .0-86 .0°F
UnOcc
Occ
000000000000-ffffffffffffh
000-999
OK
Fault
OK
Init
AddrPMode
AddrSnr
Auto Config
AssignPMode
OK
Init
DAA
Absence
Config
Error
Description
This is a text input for defining the name of the Room Zone
associated with "SensorX". It is limited to 7 characters. Upper
Case, Lower Case, and Numbers are allowed .
Actual "Temperature" value detected by SensorX in that space .
Actual "CO2" concentration value detected by SensorX in that
space .
Actual "Relative Humidity" value detected by SensorX in that
space .
Space Temperature Set point . This set point may or may not be
adjustable via the Remote QMX SensorX in the Space. That
depends on the Remote Set point Source .
This displays the current occupancy of the space . The
Occupancy can be put into Tenant Override Occupancy locally
at the Remote QMX Space Sensor by using the Local Tenant
Override on the QMX Space Sensor . The Sensor will also
display whether the Space is currently in Occupancy or not .
Pressing the Tenant Override button on the QMX Space Sensor,
while the Space is already Occupied in Tenant Override, will
reset the Tenant Override time back to its starting default value
and re-start time down .
This displays the current ID(SN) assigned for SensorX for this
Room Zone. The SensorX "ID" on the physical sensor in this
Room Zone must match this value or the sensor and C600
Controller will not communicate or transmit data properly .
If the display shows "000000000000h"s then the Sensor ID
assignment for this Room Zone is unknown. In this case the
sensor is not present on the network, it is in alarm, a different
sensor ID is attached to this room zone, a wrong type of sensor
is in this room zone, or the sensor for this room zone has yet to
be commissioned. In any case, if this displays "0...0h" then the
physical wiring and operation of the sensor in this Room Zone
must be verified and the Sensor Commissioning Procedure
Performed. Initially when Sensor Commissioning is started the
Sensor ID shown here could be incorrect to what is physically in
this Room Zone if more than one sensor is on the network .
This displays the actual "KNX" address of this device on the PL-
Link Network. It is only valid when the "SnsrX ID" above has a
valid 13 character ID and the sensor has been Commissioned.
This displays the current Alarm Status of this Sensor .
This indicates the current "Cmd" the C600 Controller is issuing
to the currently Assigned QMX Sensor for this Room Zone on
the KNX PL-Link Network . A value of "OK" means that no current
command is in process. A value of "Init" means that Sensor is in
an "initialization" command state on the network . Note that the
"Init" command happens automatically when the controller starts.
A value of "Config" means that this sensor is in the process of
being configured. Note that "AddrPMode/AddrSnr/AssignPMode"
are not used for the QMX Sensor Device use on the PL-Link
Network in this application .
This indicates the current state of the QMX SensorX for this
Room Zone . See Section 2 .2 for detailed description of each
possible state .
