MICROTECH INPUTS/OUTPUTS
Digital Inputs – 115V
#
DI5
DI6
Digital Outputs – Relay (SPST, Normally Open, 230 VAC 3 Amp
#
DO1
DO2
DO3
DO4
DO5
DO6
DO7
DO8
Digital Outputs – Solid State Relays, 24-230 VAC, 0 .5 A
#
DO9
DO10
EEV Drivers
#
EV1
EV2
OM 1373-1
Point
DHL (Fault/Normal)
Freezestat
Point
Local/Remote Status Output
Reheat Bleed Valve
Aux . Defrost Heater
Defrost Status
Heat (On/Off)
Heat Stage 1
Heat Stage 2
Heat Stage 3
Heat Stage 4
Point
Alarm
Auxiliary Output
Point
MHGRH Valve 1
Not Used
137
Comments
Comments
Comments
Comments
Sporlan 3-Way Valve:
• 200 Steps/second
• Bipolar
• 6386 steps
• 160mA current
• No holding current
• 0 overdrive open steps
• 639 overdrive close steps
• DeadTimeSync
