Figure 49: Installing the Affinity Tilt Logger with ¼" Wedge Anchors, Washers & Nuts
NOTE: If spherical washer sets are required, install 3 sets of spherical washers
and conical seats in between the base plate and concrete surface. The spherical
washer sets are intended to be used on uneven surfaces.
PSM0005A
Released: 23 Jan 2025
RST Instruments Ltd.
RSTAR Affinity Tilt Logger
Installation and User Manual
Page 46
