4.3 Technical data
4.4 Inputs and outputs
8
The current operating data and operating conditions are shown on the LCD display and in-
dicated by LEDs. Operation and input of operating parameters is carried out using a rotary
knob.
The switchgear can operate in three different operating modes:
• Filling
When the liquid level in one or two tanks drops, the pumps are automatically switched
on individually and deactivated again when the level rises.
• Draining
When the liquid level in one or two wells rises, the pumps are automatically switched on
individually and deactivated again when the level falls.
• Pressure control
The pumps are switched on/off individually and automatically depending on the actual
pressure on the output side of the system.
Date of manufacture*
Mains connection
Mains frequency
Max. current consumption per pump
Max. rated power per pump
Pump activation type
Ambient/operating temperature
Storage temperature
Max. relative humidity
Protection class
Electrical safety
Control voltage
Housing material
Details about the Hardware version (HW) and Software version (SW) can be found on the
rating plate!
*The date of manufacture is stated in accordance with ISO 8601: JJJJWww
• JJJJ = year
• W = abbreviation for week
• ww = calendar week
Inputs
Pressure detection for pressure control
Passive pressure sensor 4 to 20 mA
Pressure switch
Level measurement for filling or draining
Float switch/electrode
High water only for filling
Float switch/electrode
Dry-running protection pump for pressure control, filling or draining
Float switch/electrode
Monitoring
Thermal winding monitor (bimetallic sensor)
Thermal winding monitor (PTC sensor)
Thermal winding monitor (Pt100 sensor)
Other inputs
Extern OFF: for remote deactivation of all pumps
Key
1/2/4 = number of inputs, − = not available
Installation and operating instructions • Wilo-Control EC-WP • Ed.01/2024-08
See rating plate
See rating plate
50/60 Hz
See type designation
See rating plate
See type designation
0 ... 40 °C
-30 ... +60 °C
90%, non-condensing
IP54
Pollution degree II
See rating plate
UV-resistant polycarbonate
EC-WP 1 ... EC-WP 2 ...
1
1
2
1
1
1
−
−
1
1
−
4
1
2
2
−
−
1
