Holding register Name
(protocol)
40015 Drives on/off
(14)
40025 Control mode
(24)
40026 Actual value
(25)
40027 Current setpoint
(26)
40041 Pump mode 1
(40)
40042 Pump mode 2
(41)
40062 General status
(61)
40068 Setpoint 1
(67)
40074 Application
(73)
40139 - 40140 Fault status
(138 - 139)
40141 Acknowledge
(140)
40142 Alarm history index
(141)
40143 Fault number alarm
(142) history
40198 Status of float
(197) switch
64
Data type Scaling and unit
BOOL
ENUM
INT16 0.1 bar
INT16 0.1 bar
ENUM
ENUM
BITMAP
UINT16 0.1 bar
ENUM
BITMAP32
BOOL
UINT16 1
UINT16 0.1
BITMAP
Key
* R = read-only, RW = read- and write-accessible
Installation and operating instructions • Wilo-Control EC-WP • Ed.01/2024-08
Elements
0. p-c
10. Filling
11. Draining
0. Off
1. Manual
2. Auto
0. Off
1. Manual
2. Auto
0: SBM
1: SSM
8: EBM pump 1
9: EBM pump 2
2nd WP
0: Sensor fault
4: Dry running
5: Pump 1 error
6: Pump 2 error
15: High water
16: Overriding Off
18: Plausibility
20: Supply
0: Dry running
1: Pumps off
2: Pump 1 on
3: Pump 2 on
4: High water
5: Dry run 2
6: Pump 1 off
7: Pump 2 off
Access*
RW
R
R
R
RW
RW
R
RW
R
R
R
RW
R
R
