en
Fig. 62: Menu 5.11
Fig. 63: Menu 5.39
Fig. 64: Menu 5.40
Fig. 65: Menu 5.41
Fig. 66: Menu 5.42
Fig. 67: Menu 5.43
44
Menu no. 5.11
Name Pressure sensor measurement range
Value range 4 – 25 bar
Factory setting 16 bar
Description Defines the end value for the pressure range of the sensor.
Menu no. 5.39
Name Alarm signal with active "Extern OFF" input
Value range off, on
Factory setting off
Description If "Extern OFF" is used as input for a float switch, a "Priority
Off" alarm can be activated.
Menu no. 5.40
Name Pump kick
Value range off, on
Factory setting on
Description Switch the "Pump kick" function on or off:
•
•
Menu no. 5.41
Name "Pump kick" for Extern OFF
Value range off, on
Factory setting on
Description Select whether a pump kick may take place or not if the Extern
OFF input is active:
•
•
Menu no. 5.42
Name "Pump kick interval"
Value range 1 ... 336 h
Factory setting 24 h
Description The time interval between two test runs or after all pumps have
stopped.
Menu no. 5.43
Name "Pump kick" duration
Value range 0 ... 60 s
Factory setting 5 s
Description The switch-on time of the pump during the test run
Installation and operating instructions • Wilo-Control EC-WP • Ed.01/2024-08
off = pump kick deactivated
on = pump kick activated
off = pump kick deactivated if Extern OFF is active.
on = pump kick activated if Extern OFF is active.
