6. Assembly
6.4. Securing the Robot Arm
Description
User Manual
Bottom View of Robot Base
95
8 FG8
6x
10.50
THRU ALL
Mounting Plate with Pins for Robot Base
0.05
8 h6 -
Dimensions and hole pattern for mounting the robot.
45
95
+
0.030
+
0.008
9.5 ± ,5
+
0.030
8 FG8
+
0.008 X 13
9,5 ± 0,5
0
0
0.009
8 h6 -
0.009
190
UR20 PolyScope X
