1.1.3 Strobe Connections Behind the Port Cover
See
Amplifier.
24 VDC Auxiliary Power
Connections
Strobe Connections
See
24 VDC Auxiliary Power Source Connections (replacement of PoE power)
Connection
J6-1
J6-2
J6-3
Strobe Connections
Connection
JX-1
JX-2
JX-3
JX-4
JX-5
Operations Guide
Figure 1-8 for the additional connection options for the Paging Amplifier and Loudspeaker
Figure 1-8. Connections Behind the Port Cover
Table 1-1 for the descriptions of the connections behind the port cover.
Table 1-1. Connections Behind the Port Cover
Installing the Paging Amplifier and Loudspeaker Amplifier
J6-3 J6-2 J6-1
JX-5 JX-4 JX-3 JX-2
Description
+24VDC
Ground
Chassis Ground
Description
Ground
Strobe positive power (+24V)
Ground
I2C data
I2C clock
932064A
Strobe Connections Behind the Port Cover
JX-1
