7.2.5 To close the outdoor unit
7.2.6 To open the indoor unit
EPRA14~18D + ETSH/X(B)16P30+50E
Daikin Altherma 3 H HT ECH₂O
4P679467-1D – 2023.11
1 Put the compressor cover piece on its place. Use the screws (4x) of the
transportation stay to fix it (see
4
stay" [ 71]).
NOTICE
When closing the outdoor unit cover, make sure that the tightening torque does NOT
exceed 4.1 N•m.
3 2
NOTICE
The top cover can only be removed if the switch box is lowered.
Overview
b
a
a User interface panel
b Switch box cover
7
"7.2.3 To remove the transportation
4 1
3 2
3×
4 1
Unit installation
|
