Field settings table
Breadcrumb Setting name
9.I [6-01] The temperature difference determining the heat pump OFF
temperature.
9.I [6-02] What is the capacity of the booster heater?
9.I [6-03] What is the capacity of the backup heater step 1?
9.I [6-04] What is the capacity of the backup heater step 2?
9.I [6-07] --
9.I [6-08] What is the hysteresis to be used in reheat mode?
9.I [6-09] --
9.I [6-0A] What is the desired comfort storage temperature?
9.I [6-0B] What is the desired eco storage temperature?
9.I [6-0C] What is the desired reheat temperature?
9.I [6-0D] What is the desired DHW production type?
9.I [6-0E] What is the maximum temperature setpoint?
9.I [7-00] Domestic hot water booster heater overshoot temperature.
9.I [7-01] Domestic hot water booster heater hysteresis.
9.I [7-02] How many leaving water temperature zones are there?
9.I [7-03] --
9.I [7-04] --
9.I [7-05] Boiler efficiency
9.I [7-06] HP forced OFF
9.I [7-07] BBR16 activation*
*BBR16 settings are only visible when the language of the user
interface is set to Swedish.
9.I [7-09] How much is the minimum pump PWM value.
9.I [7-0A] Additional zone fixed pump PWM, in case a bizone kit is installed.
9.I [7-0B] Main zone fixed pump PWM, in case a bizone kit is installed.
9.I [7-0C] Time needed by the mixing valve to turn from one side to the
other, in case a bizone kit is installed.
9.I [7-0D] Hysteresis value used to control the tank bivalent in case it's
supporting space heating operation
9.I [7-0E] Offset on the setpoint to determine when the tank is high enough
to go the excess state
9.I [8-00] Minimum running time for domestic hot water operation.
9.I [8-01] Maximum running time for domestic hot water operation.
9.I [8-02] Anti-recycling time.
(*1) *X*_(*2) *H*_(*3) *B*_(*4) *EKECBUA*3V_
(*5) *EKECBUA*6V_(*6) *EKECBUA*9W_(*7) BUH less_
(*8) 300L tank_(*9) E_(*10) E7
Range, step
Default value
R/W 0~10°C, step: 1°C
0°C
R/W
0~10kW, step: 0,2kW
0kW
R/O 0~10kW, step: 0,2kW
0kW
2kW (*5)
3kW (*4, *6, *7)
R/W (*5, 0~10kW, step: 0,2kW
*6)
0kW (*4)
R/O (*4,
3kW (*7)
*7)
4kW (*5)
6kW (*6)
0
R/W 2~20°C, step: 1°C
10°C
0
R/W 30~[6-0E]°C, step: 1°C
60°C
R/W 30~min(50, [6-0E])°C, step: 1°C
45°C
R/W 30~min(50, [6-0E])°C, step: 1°C
45°C
R/W
0: Reheat only
3 scheduled reheat
R/W E-07 = 4
40~ 75°C, step: 1°C
65°C
R/W 0~4°C, step: 1°C
0°C
R/W 2~40°C, step: 1°C
2°C
R/W 0: Single zone
1: Dual zone
2,5
0
R/W 0: Very high
1: High
2: Medium
3: Low
4: Very low
R/W
0: Disabled
1: Enabled
R/W 0: No
1: Yes
R/W 20%
R/W 20~95%, step 5%
95%
R/W 20~95%, step 5%
95%
R/W 20~300 seconds, step 5 sec
125 seconds
R/W 2~20, step 0,5 °C
4 °C
R/W 2~22, step 0,5 °C
7 °C
R/W
0~20 min, step 1 min
1 min
R/W 5~95 min, step: 5 min
30 min
R/W 0~10 hour, step: 0,5 hour
0,5 hour
