Daikin ETSX16E Installer's Reference Manual page 296

Field settings table
Breadcrumb Setting name
2.7 [2-0C] Emitter type
└─ Setpoint range
2.8.1 [9-01] Heating minimum
2.8.2 [9-00] Heating maximum
2.8.3 [9-03] Cooling minimum
2.8.4 [9-02] Cooling maximum
Main zone
2.9 [C-07] Control
2.A [C-05] Ext Thermostat type
└─ Delta T
2.B.1 [1-0B] Delta T heating
2.B.2 [1-0D] Delta T cooling
└─ Modulation
2.C.1 [8-05] Modulation
2.C.2 [8-06] Max modulation
└─ Shut off valve
2.D.1 [F-0B] During thermo
2.D.2 [F-0C] During cooling
Main zone
2.E WD curve type
Additional zone
3.4 Setpoint mode
└─ Heating WD curve
3.5 [0-00] Leaving water value for high ambient temp. for LWT add zone
heating WD curve.
3.5 [0-01] Leaving water value for low ambient temp. for LWT add zone
heating WD curve.
(*1) *X*_(*2) *H*_(*3) *B*_(*4) *EKECBUA*3V_
(*5) *EKECBUA*6V_(*6) *EKECBUA*9W_(*7) BUH less_
(*8) 300L tank_(*9) E_(*10) E7
Range, step
Default value
R/W 0: Underfloor heating
1: Fancoil unit
2: Radiator
R/W 15~37°C, step: 1°C
25°C
R/W ([2- [2-0C]=2:
0C] ≠ 2) 37~70, step: 1°C
R/O ([2- 70°C
0C] = 2)
[2-0C]≠2:
37~55, step: 1°C
55°C
R/W 5~18°C, step: 1°C
7°C
R/W 18~22°C, step: 1°C
22°C
R/W
0: Leaving water
1: External room thermostat
2: Room thermostat
R/W 1: 1 contact
2: 2 contacts
R/W(*10) 3~10°C, step: 1°C (*9)
[2-0D]=2 [2-0C] ≠ 2 (Radiator)
R/O (*9) 3~12°C, step: 1°C (*10)
5°C
[2-0C] = 2 (Radiator)
10~12°C, step: 1°C (*10)
10°C
R/W 3~10°C, step: 1°C
5°C
R/W 0: No
1: Yes
R/W 0~10°C, step: 1°C
5°C
R/W 0: No
1: Yes
R/W 0: No (*10)
1: Yes (*9)
R/W 0: 2-points
1: Slope-Offset
0: Fixed
1: WD heating, fixed cooling
2: Weather dependent
R/W [9-05]~min(45,[9-06])°C, step: 1°C
[2-0C]=0
25°C
[2-0C]=1
35°C
[2-0C]=2
35°C
R/W [9-05]~[9-06]°C, step: 1°C
[2-0C]=0
35°C
[2-0C]=1
45°C
[2-0C]=2
65°C
3/19
4P681797-1C - 2023.07
