Daikin ETSX16E Installer's Reference Manual page 295

2/19
Field settings table
Breadcrumb Setting name
Room
└─ Antifrost
1.4.1 [2-06] Activation
1.4.2 [2-05] Room setpoint
└─ Setpoint range
1.5.1 [3-07] Heating minimum
1.5.2 [3-06] Heating maximum
1.5.3 [3-09] Cooling minimum
1.5.4 [3-08] Cooling maximum
Room
1.6 [2-09] Room sensor offset
1.7 [2-0A] Room sensor offset
└─ Room comfort setpoint
1.9.1 [9-0A] Heating comfort setpoint
1.9.2 [9-0B] Cooling comfort setpoint
Main zone
2.4 Setpoint mode
└─ Heating WD curve
2.5 [1-00] Low ambient temp. for LWT main zone heating WD curve.
2.5 [1-01] High ambient temp. for LWT main zone heating WD curve.
2.5 [1-02] Leaving water value for low ambient temp. for LWT main zone
heating WD curve.
2.5 [1-03] Leaving water value for high ambient temp. for LWT main zone
heating WD curve.
└─ Cooling WD curve
2.6 [1-06] Low ambient temp. for LWT main zone cooling WD curve.
2.6 [1-07] High ambient temp. for LWT main zone cooling WD curve.
2.6 [1-08] Leaving water value for low ambient temp. for LWT main zone
cooling WD curve.
2.6 [1-09] Leaving water value for high ambient temp. for LWT main zone
cooling WD curve.
Main zone
4P681797-1C - 2023.07
Range, step
Default value
R/W 0: No
1: Yes
R/W 4~16°C, step: 1°C
8°C
R/W 12~18°C, step: 1°C
12°C
R/W 18~30°C, step: 1°C
30°C
R/W 15~25°C, step: 1°C
15°C
R/W 25~35°C, step: 1°C
35°C
R/W -5~5°C, step: 0,5°C
0°C
R/W -5~5°C, step: 0,5°C
0°C
R/W [3-07]～[3-06]°C, step: 0,5°C
23°C
R/W [3-09]～[3-08]°C, step: 0,5°C
23°C
0: Fixed
1: WD heating, fixed cooling
2: Weather dependent
R/W -40~5°C, step: 1°C
-15°C
R/W 10~25°C, step: 1°C
15°C
R/W [9-01]~[9-00], step: 1°C
[2-0C]=0
35°C
[2-0C]=1
45°C
[2-0C]=2
65°C
R/W [9-01]~min(45, [9-00])°C , step: 1°C
[2-0C]=0
25°C
[2-0C]=1
35°C
[2-0C]=2
35°C
R/W 10~25°C, step: 1°C
20°C
R/W
25~43°C, step: 1°C
35°C
R/W [9-03]~[9-02]°C, step: 1°C
22°C
R/W [9-03]~[9-02]°C, step: 1°C
[2-0C]=0
18°C
[2-0C]=1
7°C
[2-0C]=2
18°C
(*1) *X*_(*2) *H*_(*3) *B*_(*4) *EKECBUA*3V_
(*5) *EKECBUA*6V_(*6) *EKECBUA*9W_(*7) BUH less_
(*8) 300L tank_(*9) E_(*10) E7
