4 | About the box
4.1.3 To remove the accessories from the outdoor unit
Installer reference guide
24
3
4
a
c
b
e
d
ENERG Y IJA ENERG Y IJA
IE IA IE IA
f g
h
a O-ring for drain socket
b Drain socket
c Shut-off valve (with integrated filter)
d Thermistor fixture (for installations in areas with low ambient temperatures)
e Compressor cover piece
f Installation manual – Outdoor unit
g Energy label
h Discharge grille (upper + lower part)
i Installation manual – Discharge grille
