6.6 Setting up the power consumption control
EPRA14~18D + ETSH/X(B)16P30+50E
Daikin Altherma 3 H HT ECH₂O
4P679467-1D – 2023.11
b Electrical cabinet (L
c Power meter (L
d Power meter (L
e Fuse (L /N)
1
f Fuse (L /L /L
1 2
g Outdoor unit (L
h Indoor unit (L
i Backup heater (L
You can use the following power consumption controls. For more information
about the corresponding settings, see
#
1 "6.6.1 Permanent power
▪ Allows you to limit the power consumption of the entire heat pump
system (sum of indoor unit and backup heater) with one permanent
setting.
▪ Limitation of power in kW or current in A.
2 "6.6.2 Power limitation activated by digital
▪ Allows you to limit the power consumption of the entire heat pump
system (sum of indoor unit and backup heater) via 4 digital inputs.
▪ Limitation of power in kW or current in A.
3 "6.6.4 BBR16 power
▪ Restriction: Only available in Swedish language.
▪ Allows you to comply with BBR16 regulations (Swedish energy
regulations).
▪ Limitation of power in kW.
▪ Can be combined with the other kW power consumption controls. If you
do so, the unit uses the most restrictive control.
NOTICE
It is possible to install a field fuse with lower than recommended rating over the heat
pump. For this you must modify field setting [2‑0E] according to the maximum
allowed current over the heat pump.
Note that field setting [2‑0E] overrules all power consumption control settings.
Power limiting the heat pump will reduce performance.
NOTICE
Set a minimum power consumption of ±3.6 kW to guarantee:
▪
Defrost operation. Otherwise, if defrosting is interrupted several times, the heat
exchanger will freeze up.
▪
Space heating and DHW production by allowing the backup heater step 1.
▪
Disinfection operation.
/L /L /N): Normal kWh rate power supply
1 2 3
/N)
1
/L /L /N)
1 2 3
/N)
3
/N)
1
/N)
1
/L /L /N)
1 2 3
"Power consumption
Power consumption control
4
limitation" [ 62]
limitation" [ 4 64]
6 Application guidelines
|
4
control" [ 215].
4
inputs" [ 62]
