Daikin ETSX16E Installer's Reference Manual page 297

4/19
Field settings table
Breadcrumb Setting name
3.5 [0-02] High ambient temp. for LWT add zone heating WD curve.
3.5 [0-03] Low ambient temp. for LWT add zone heating WD curve.
└─ Cooling WD curve
3.6 [0-04] Leaving water value for high ambient temp. for LWT add zone
cooling WD curve.
3.6 [0-05] Leaving water value for low ambient temp. for LWT add zone
cooling WD curve.
3.6 [0-06] High ambient temp. for LWT add zone cooling WD curve.
3.6 [0-07] Low ambient temp. for LWT add zone cooling WD curve.
Additional zone
3.7 [2-0D] Emitter type
└─ Setpoint range
3.8.1 [9-05] Heating minimum
3.8.2 [9-06] Heating maximum
3.8.3 [9-07] Cooling minimum
3.8.4 [9-08] Cooling maximum
Additional zone
3.A [C-06] Thermostat type
└─ Delta T
3.B.1 [1-0C] Delta T heating
3.B.2 [1-0E] Delta T cooling
Additional zone
3.C WD curve type
Space heating / cooling
└─ Operation range
4.3.1 [4-02] Space heating OFF temp
4.3.2 [F-01] Space cooling OFF temp
Space heating / cooling
4.4 [7-02] Number of zones
4.5 [F-0D] Pump operation mode
4.6 [E-02] Unit type
4P681797-1C - 2023.07
Range, step
Default value
R/W 10~25°C, step: 1°C
15°C
R/W -40~5°C, step: 1°C
-15°C
R/W [9-07]~[9-08]°C, step: 1°C
[2-0C]=0
18°C
[2-0C]=1
7°C
[2-0C]=2
18°C
R/W [9-07]~[9-08]°C, step: 1°C
22°C
R/W 25~43°C, step: 1°C
35°C
R/W 10~25°C, step: 1°C
20°C
R/O 0: Underfloor heating
1: Fancoil unit
2: Radiator
R/W 15~37°C, step: 1°C
25°C
R/W ([2- [2-0C]=2:
0C] ≠ 2) 37~70, step: 1°C
R/O ([2- 70°C
0C] = 2) [2-0C]≠2:
37~55, step: 1°C
55°C
R/W 5~18°C, step: 1°C
7°C
R/W 18~22°C, step: 1°C
22°C
R/W 1: 1 contact
2: 2 contacts
R/W(*10) 3~10°C, step: 1°C (*9)
[2-0D]=2 [2-0C] ≠ 2 (Radiator)
R/O (*9) 3~12°C, step: 1°C (*10)
5°C
[2-0C] = 2 (Radiator)
10~12°C, step: 1°C (*10)
10°C
R/W 3~10°C, step: 1°C
5°C
R/O 0: 2-points
1: Slope-Offset
R/W 14~35°C, step: 1°C
35°C
R/W 10~35°C, step: 1°C
20°C
R/W 0: Single zone
1: Dual zone
R/W 0: Continuous
1: Sample
2: Request
R/W (*1)
0: Reversible (*1)
R/O (*2)
1: Heating only (*2)
(*1) *X*_(*2) *H*_(*3) *B*_(*4) *EKECBUA*3V_
(*5) *EKECBUA*6V_(*6) *EKECBUA*9W_(*7) BUH less_
(*8) 300L tank_(*9) E_(*10) E7
