Daikin ETSX16E Installer's Reference Manual page 310

Field settings table
Breadcrumb Setting name
9.I [C-02] Is an external backup heat source connected?
9.I [C-03] Bivalent activation temperature.
9.I [C-04] Bivalent hysteresis temperature.
9.I [C-05] What is the thermo request contact type for the main zone?
9.I [C-06] What is the thermo request contact type for the add. zone?
9.I [C-07] What is the unit control method in space operation?
9.I [C-08] Which type of external sensor is installed?
9.I [C-09] What is the required alarm output contact type?
9.I [C-0A] --
9.I [C-0B] --
9.I [C-0C] --
9.I [C-0D] --
9.I [C-0E] --
9.I [D-00] Which heaters are permitted if prefer. kWh rate PS is cut?
9.I [D-01] Contact type of preferential kWh rate PS installation?
9.I [D-02] Which type of DHW pump is installed?
9.I [D-03] Leaving water temperature compensation around 0°C.
9.I [D-04] Is a demand PCB connected?
9.I [D-05] Is the pump allowed to run if prefer. kWh rate PS is cut?
9.I [D-07] Is a solar kit connected?
9.I [D-08] Is an external kWh meter used for power measurement?
9.I [D-09] Is an external kWh meter used for power measurement, kWh
meter used for smart grid?
(*1) *X*_(*2) *H*_(*3) *B*_(*4) *EKECBUA*3V_
(*5) *EKECBUA*6V_(*6) *EKECBUA*9W_(*7) BUH less_
(*8) 300L tank_(*9) E_(*10) E7
Range, step
Default value
R/W 0: Off
1: Direct (SH)
2: Indirect (DHW) (*3)
3: Indirect (DHW + SH)
R/W -25~25°C, step: 1°C
0°C
R/W 2~10°C, step 1°C
3°C
R/W 1: 1 contact
2: 2 contacts
R/W 1: 1 contact
2: 2 contacts
R/W 0: Leaving water
1: External room thermostat
2: Room thermostat
R/W 0: No
1: Outdoor
2: Room
R/W 0: Abnormal
1: Normal
0
0
0
0
0
R/W 0: No
1: Only BSH
2: Only BUH
3: All
R/W 0: No
1: Open
2: Closed
3: Smart Grid
R/W 0: No DHW pump
1: Instant hot water
2: Disinfection
3: Circulation
4: Circulation and disinfection
R/W 0: No
1: increase 2°C, span 4°C
2: increase 4°C, span 4°C
3: increase 2°C, span 8°C
4: increase 4°C, span 8°C
R/W 0: No
1: Pwr consmp ctrl
R/W 0: No
1: Yes
R/W 0: No
1: Yes (DHW)
2: Yes (DHW + SH)
R/W 0: No
1: 0,1 pulse/kWh
2: 1 pulse/kWh
3: 10 pulse/kWh
4: 100 pulse/kWh
5: 1000 pulse/kWh
R/W 0: No
1: 0,1 pulse/kWh
2: 1 pulse/kWh
3: 10 pulse/kWh
4: 100 pulse/kWh
5: 1000 pulse/kWh
6: 100 pulse/kWh (PV meter)
7: 1000 pulse/kWh (PV meter)
17/19
4P681797-1C - 2023.07
