RANGE HOOD USE

Range Hood Control Panel

Remote
Delayed
Control
Auto
Sensor
Shut Off
Light
Remote Control Sensor
The Remote Control Sensor receives infrared (IR) signal
from the remote control.
The maximum distance for IR data transmission is 10
feet and requires direct line of sight.
The transmission distance may vary depending
on the room temperature and the condition of the
battery in the remote control.
Delayed Auto Shut-Off
When the hood is operating in any speed, touch this
button once will activate the Delayed Auto Shut Off
function.
Touch the Speed (-) or Speed (+) button to adjust the
duration of the countdown timer.
The timer can be adjusted between 1 minute to15
minutes using the Speed (-) or Speed (+) button.
(default 5 minutes if the timer is not set manually.)
The Delayed Auto Shut Off Indicator will be
illuminated in the LCD Display once the timer is set
and counting.
The timer will start immediately once it's set. When
it reaches 0, the Range Hood and the Light will be
turned off automatically.
Clock / Current Time Display
When the Delayed Auto Shut Off function is not
activated, the LCD Display will show the current
time of the day.
THE CLOCK CAN ONLY BE SET WHILE THE BLOWER
IS OFF.
To set the Clock:
Touch and hold the Delayed Auto Shut Off
button for 3 seconds. The hour indicator will
flash.
Touch the Speed (-) or Speed (+)button to adjust
to the desired hours.
When done setting the hour, touch the Delayed
Auto Shut Off button again. The minute
indicator will flash.
Touch the Speed (-) or Speed (+) button to
adjust to the desired minutes.
When done setting the minutes, all settings will
be saved automatically if there are no additional
When the Delayed Auto Shut Off fuction is activated
while the blower is running, a countdown timer will
show up in the LCD Display.
Light - 2 Light Levels
Touch the Light button once and the lamps will turn
on at the max light level.
Speed
Power
Touch the Light button again and the lamps will go
down to the next light level.
Touch the Light button the 3rd time and the lamps will
turn off.
The Light button operates independently from the
Power button. It works even when the range hood is
not turned on.
The Delayed Auto Shut Off function will turn off the
Light automatically when the timer reaches 0.
Speed (-) (+)
While the range hood is off:
Power
Touch the Power button once while the hood is off to
turn on the hood and set it to Speed 1 (F1 - the lowest
speed).
Touch the Power button once while the hood is
running to shut it off immediately.
WARNING
Read all instrutions and warnings before using the
hood.
DO NOT use the hood when there are no safety grills
and filters.
NEVER dispose cigarette ashes, ignitable substances,
or any foreign objects into blowers.
NEVER leave the cooking appliances unattended.
When frying, the oil in the pan can easily overheat and
catch on fire. The risk of self-combustion is higher
when the oil has been used several times.
NEVER cook on "open" flames under the range hood.
Check deep-fryers during use: Superheated oil may be
flammable.
operations within 5 seconds.
Touch the Speed (-) button to turn on the Range
Hood on Speed 1 (F1 - the lowest speed).
Touch the Speed (+) button to turn on the Range
Hood on Speed 2 (F2).
Touch (-) or (+) again to change the blower speed as
indicated in the LCD Display until the desired speed
is reached.
9
