Awoco RH-WT-36 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Important!
Make sure to manually spin the fan wheel to check if it's running without
any obstacles before the test run.
If the fan wheel is unbalanced or in contact with the casing, refer to Page
11 for how to re-seat the fan wheel.
OWNER'S MANUAL
Range Hood
RH-WT Wall Mounted Series
Ver. RH-WT-2021B
Test Run
Before
Installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RH-WT-36 and is the answer not in the manual?

Questions and answers

Related Manuals for Awoco RH-WT-36

Summary of Contents for Awoco RH-WT-36

  • Page 1 Ver. RH-WT-2021B Important! Make sure to manually spin the fan wheel to check if it's running without any obstacles before the test run. If the fan wheel is unbalanced or in contact with the casing, refer to Page 11 for how to re-seat the fan wheel. OWNER'S MANUAL Range Hood Test Run...
  • Page 2 RANGE HOOD BEFORE INSTALLATION FOR ANY DEFECTS In case of this manual destroyed or lost, please visit OR SHIPPING DAMAGE: https:/ /www.awoco.com and download a digital version. Installation Overview 1. This range hood model is packed in 2 packages. Take out the range hood and its accessories from both packages carefully.

  • Page 3: Table Of Contents

    Table of Contents Important Safety Instructions Installation Preparations Venting Requirements Venting System Setup Duct Run Minimum Size Electrical Requirement Installation Installing the Range Hood Connecting the Vent System Electrical Connection Installing the Baffle Filters Completing the Installation Range Hood Use Range Hood Control Panel Range Hood Care Clean the Exterior Surfaces...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR spillovers that may ignite. Heat oils slowly on low or PERSONAL INJURY, PLEASE READ THE FOLLOWING medium settings. CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, • Always turn the hood ON when cooking at high INSTALL, OPERATE OR MAINTAIN THE RANGE HOOD: heat or when flambeing food (i.e.

  • Page 5: Installation Preparations

    INSTALLATION PREPARATIONS Venting Requirements DO NOT • Have the venting system go vertically from the • End the venting system in an enclosed area indoors. range hood to the roof if possible. • Use plastic vent. • Have 24"-30" distance between the cooktop and •...

  • Page 6: Duct Run Minimum Size

    INSTALLATION PREPARATIONS IMPORTANT! • If long duct run is needed, increase the duct size from 6" to 7" or 8" to 9". • If a reducer is needed, use a long reducer instead of a pancake reducer and install it as far away from the range hood as possible.

  • Page 7: Installation

    INSTALLATION Installing the Range Hood Install the bottom half of the Chimney to the Hood • Body. • Determind how high you want to install your range hood above the stove top and draw a horizontal line with a pencil. 24" to 30" Height is recommended. The following steps requires 2 or more people: Remove the Baffle Filters to reduce the weight for •...

  • Page 8: Connecting The Vent System

    INSTALLATION Use a Stud Finder to locate 2 Studs within the Installing the Oil Collector • width of the Hood Body. Drill 4 new holes on the backplate, aligning with the Studs, and screw in 4 • Locate the recess support in the bottom, near the screws to securely mount the Range Hood to the rear of the range hood.

  • Page 9: Range Hood Use

    RANGE HOOD USE Range Hood Control Panel Touch the Light button to check and validate the time. • • When the Delayed Auto Shut Off fuction is activated Remote Control Delayed Auto while the blower is running, a countdown timer will Sensor Shut Off Light...

  • Page 10: Range Hood Care

    RANGE HOOD CARE Cleaning front, align and insert the filter. • Pull the spring release handle and push the filter WARNING into position. • Release the handle. • To reduce the risk of electrical shock, DO NOT clean • Repeat the steps for the remaining filters. the hood while it's operating.

  • Page 11: Range Hood Troubleshooting

    RANGE HOOD TROUBLESHOOTING Before Calling for Service Issue Possible Cause / Solution • Check if the range hood is plugged in. Make sure that all The range hood doesn't turn on power is turned ON, the fuse isn't blown and all electrical wirings are properly connected.
  • Page 12 RANGE HOOD TROUBLESHOOTING How to adjust and replace the fan wheel • Disconnect the main power. • Remove the hood from its mounting location. • Remove the duct and expose the blower fan wheel. Follow these instructions to re-seat the fan wheel: •...

  • Page 13: Warranty

    This limited warranty is applied to the original retail * Awoco is not responsible for any labor costs associated purchaser and valid only for products purchased for home use. with removing, servicing, installing, or determining the source of problems with our products from third-party service providers.
  • Page 14 Product Support and Additional Information: If you need assistance using your product or you would like to start the warranty service: • Contact us at 1-888-412-3428, between 11 AM and 5 PM, Monday - Friday, Pacific Time. • Contact us at www.awoco.com/pages/contact-us.
  • Page 15 Website: www.awoco.com Customer Support: 1-888-412-3428...
