Awoco RH-BQ-R Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
awoco.com
Built-In/Insert Series
w/ Remote Control
* Unpack & Check for Shipping Damages *
Important!
•
Make sure to manually spin the fan wheel to check if it's
running without any obstacles before the test run.
•
If the fan wheel is unbalanced or in contact with the
casing, refer to Page 11 for how to re-seat the fan wheel.
* Test Run Before Installation *
Range Hood
OWNER'S
MANUAL
Manual Version:
RH-BQ-R-2024A
For Models:
RH-BQ-R

Advertisement

loading
Need help?

Need help?

Do you have a question about the RH-BQ-R and is the answer not in the manual?

Questions and answers

Related Manuals for Awoco RH-BQ-R

Summary of Contents for Awoco RH-BQ-R

  • Page 1 Range Hood awoco.com OWNER'S MANUAL Built-In/Insert Series Manual Version: RH-BQ-R-2024A w/ Remote Control For Models: RH-BQ-R Important! • Make sure to manually spin the fan wheel to check if it's running without any obstacles before the test run. • If the fan wheel is unbalanced or in contact with the casing, refer to Page 11 for how to re-seat the fan wheel.

  • Page 2: Installation Overview

    PLEASE FOLLOW THESE INSTRUCTIONS TO TEST THE RANGE HOOD BEFORE INSTALLATION FOR ANY In case of this manual destroyed or lost, please DEFECTS OR SHIPPING DAMAGE: visit https:/ /www.awoco.com and download a digital version. 1. Remove the range hood and accessories from Installation Overview the package carefully.

  • Page 3: Table Of Contents

    Important Safety Instructions Installation Preparations Venting Requirements Venting System Setup Electrical Requirement Assembling The Vent Adapter Installation Installing The Hood Unit Electrical Connection Installing The Mesh Filters Optional Ductless Configuration Completing The Installation Product Dimension Diagrams Range Hood Use Range Hood Control Panel Range Hood Care Clean The Exterior Surfaces Clean Or Replace The Mesh Filters...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK • Always turn the hood ON when cooking at OR PERSONAL INJURY, PLEASE READ THE high heat or when flambeing food (i.e. Crepes FOLLOWING CAREFULLY BEFORE ATTEMPTING Suzette, Cherries Jubilee, Peppercorn Beef TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN Flambé).

  • Page 5: Installation Preparations

    INSTALLATION PREPARATIONS Venting Requirements DO NOT • Have the venting system go vertically from the • End the venting system in an enclosed area range hood to the roof if possible. indoors. • Have 24"-30" distance between the cooktop • Use plastic vent.

  • Page 6: Electrical Requirement

    INSTALLATION PREPARATIONS IMPORTANT! Electrical Requirements • If long duct run is needed, increase the duct • A 120V, 60Hz., AC only, 3A fused electrical size from 6" to 7" or 8" to 9". circuit is required. • If a reducer is needed, use a long reducer •...

  • Page 7: Installation

    INSTALLATION Installing The Range Hood Note • If the wood hood is enclosed at the bottom, make a cutout on the board so that the Range Hood can fit into the wood hood. • Guide the duct into the Wood Hood. Temporarily secure the top of the duct to the ceiling opening or wall opening.

  • Page 8: Installing The Mesh Filters

    INSTALLATION WARNING Electrical Shock Hazard Disconnect power before servicing • In case of a direct connection to the house wiring is preferred, do the following: • Disconnect the power. • Cut off the plug from the power cord. • Connect the wires from the power cord to the wires from the house wiring using UL listed wire connectors.

  • Page 9: Product Dimension Diagrams

    INSTALLATION RH-BQ-R Dimensions Wood Hood Cut-Out Size: 26-1/8" x 10-3/8" 10-3/8'' 11-3/4'' 2-1/2'' 26'' 13-3/8'' 27-3/4'' 14-1/2'' RH-BQ-R30 Wood Hood Cut-Out Size: 34" x 10-3/8" 10-3/8'' 10-3/8'' 11-3/4'' 2-1/2'' 33-7/8'' 13-3/8'' 35-3/8'' 14-1/2'' RH-BQ-R36...

  • Page 10: Range Hood Use

    RANGE HOOD USE Range Hood Control Panel • When the Delayed Auto Shut Off fuction is activated while the blower is running, a Remote Delayed countdown timer will show up in the LCD Control Auto Sensor Shut Off Light Display. Light Touch the Light button once and the lamps will •...

  • Page 11: Range Hood Care

    RANGE HOOD CARE Cleaning Replacing The Filters WARNING • Replace the mesh filters immediately should • To reduce the risk of electrical shock, DO NOT they become worn out due to aging or clean the hood while it's operating. prolonged usage. •...

  • Page 12: Range Hood Troubleshooting

    RANGE HOOD TROUBLESHOOTING Before Calling For Service Issue Possible Cause / Solution • Check if the range hood is plugged in. Make sure that all power The range hood doesn't turn on is turned ON, the fuse isn't blown and all electrical wirings are properly connected.

  • Page 13: How To Replace The Fan Wheel

    • Manually flip the air damper blades to see where/how they are stuck and fix it accordingly. • If the air damper is broken beyond repair, contact Awoco customer service for a replacement. Figure 9 Fixing Screw...

  • Page 14: Warranty

    • Repair parts or replacement products will be provided by Awoco, free of charge, on an • Contact us at 1-888-412-3428, between 10 exchange basis, and will be either new or AM and 5 PM, Monday - Friday, Pacific Time.
  • Page 15 This page is meant to be blank.
  • Page 16 Website: www.awoco.com Customer Support: 1-888-412-3428...
