Model: RH-UC7, RH-UC7-BLK

Manual Revision: 2024A

6", 7" or 8" Top

Round Adapter

4 other optional adapters available to fit your need.

* The adapters are interchangeable between each other.

* Contact us if you wish to exchange your existing adapter to a different one.

Air Damper

3-1/4" x 10" Top

Rectangular Adapter

Comes with 1 adapter of your choice by default.

* Unpack & Check for Shipping Damages *

* Test Run Before Installation *

Range Hood

OWNER'S

MANUAL

Under Cabinet Series

6 Speeds

Hand Gesture Control | Remote Control

Caution !

Make sure the air damper can

open freely after the installation.

3-1/4" x 10" Rear

Rectangular Adapter

Table of Contents

Need help?

Do you have a question about the RH-UC7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Awoco RH-UC7

Page 1 Range Hood awoco.com OWNER'S MANUAL Model: RH-UC7, RH-UC7-BLK Manual Revision: 2024A Under Cabinet Series 6 Speeds Hand Gesture Control | Remote Control Air Damper Caution ! Make sure the air damper can open freely after the installation. 6", 7" or 8" Top 3-1/4"...
Page 2: Installation Overview
This manual provides a general insight on the installation and may not include solutions for all possible issues that may occur. In case of this manual destroyed or lost, please visit https:/ /www.awoco.com and download a digital version.
Page 3: Table Of Contents
Important Safety Instructions Installation Preparations Venting Requirements Venting System Setup Minimum Duct Size Electrical Requirement Installation Installing the Range Hood Connecting the Vent System Electrical Connection Installing the Oil Collector Installing the Baffle Filters Completing the Installation Range Hood Use Range Hood Control Panel Range Hood Care Clean the Exterior Surfaces...
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC low or medium settings. SHOCK OR PERSONAL INJURY, PLEASE • Always turn the hood ON when cooking at READ THE FOLLOWING CAREFULLY BEFORE high heat or when flambeing food (i.e. Crepes ATTEMPTING TO ASSEMBLE, INSTALL, Suzette, Cherries Jubilee, Peppercorn Beef OPERATE OR MAINTAIN THE RANGE HOOD:...
Page 5: Installation Preparations
INSTALLATION PREPARATIONS VENTING REQUIREMENTS DO NOT • Have the venting system go vertically from • End the venting system in an enclosed area the range hood to the roof if possible. indoors. • Have 24"-30" distance between the cooktop • Use plastic vent.
Page 6: Minimum Duct Size
INSTALLATION PREPARATIONS IMPORTANT! • If long duct run is needed, increase the duct size from 8" to 9" or 10". • If a reducer is needed, use a long reducer instead of a pancake reducer and install it as far away from the range hood as possible. Reducing the duct size will restrict and decrease the speed of the airflow and hense lower the range hood's performance.
Page 7: Installation
INSTALLATION INSTALLATION INSTRUCTIONS CAUTION CAUTION! Make sure the range hood is securely mounted before releasing. Wear gloves to protect against sharp edge. INSTALLING THE RANGE HOOD CONNECTING THE VENT SYSTEM • For installing under the cabinet with recessed • Depending on the vent adapter that comes bottom, attach a 4"...
Page 8: Installing The Oil Collector
INSTALLATION INSTALLING THE OIL CONTAINER months regularly. Follow the cleaning guide in Page 11. • Locate 2 Brackets at the hood bottom, one on COMPLETING THE INSTALLATION each side, near the back of the range hood. • Align the oil container with the hood body and slide it, from front to back, into the Brackets.
Page 9: Range Hood Use
RANGE HOOD USE Range Hood Control Panel through the control panel or via the remote. Hand Gesture Control Lock Power Light Speed REMOTE CONTROL SENSOR • The remote control sensor receives infrared (IR) signal from the remote control. • The maximum distance for IR data Hand Gesture Sensors transmission is 10 feet and requires direct line of sight.
Page 10 RANGE HOOD USE WARNING to confirm and save all settings. Touch the Light button to check and • Read all instrutions and warnings before using validate the time. the hood. • When the Delayed Auto Shut Off fuction is activated while the blower is running, a •...
Page 11: Range Hood Care
This range hood uses 1x 3W rectangular LED. bleaches or cleaning compound that contains • If the LED lamp is defective and needs to be harmful chemicals. replaced, contact Awoco Customer Support for a free replacement. Cleaning Method: • Noncorrosive or nonabrasive liquid detergent soap or all-purpose liquid cleanser.
Page 12: Range Hood Troubleshooting
RANGE HOOD TROUBLESHOOTING Before Calling for Service Issue Possible Cause / Solution • Check if the range hood is plugged in. Make sure that all power The range hood doesn't turn on is turned ON, the fuse isn't blown and all electrical wirings are properly connected.
Page 13: Warranty
• Repair parts or replacement products will be provided by Awoco, free of charge, on an • Contact us at 1-888-412-3428, between 10 exchange basis, and will be either new or AM and 5 PM, Monday - Friday, Pacific Time.
Page 14 Website: www.awoco.com Customer Support: 1-888-412-3428 Email: sales@awoco.com...
