- Page 1 Range Hood awoco.com OWNER'S MANUAL Model: RH-S10-MS Manual Revision: 2024A Under Cabinet Series Hand Gesture Control & Remote Control * Unpack & Check for Shipping Damages * * Test Run Before Installation *...
- Page 2 This manual provides a general insight on the installation and may not include solutions for all possible issues that may occur. In case of this manual destroyed or lost, please visit https:/ /www.awoco.com and download a digital version.
- Page 3 Important Safety Instructions Installation Preparations Venting Requirements Venting System Setup Minimum Duct Size Electrical Requirement Installation Installing the Range Hood Connecting the Vent System Electrical Connection Installing the Baffle Filters Completing the Installation Range Hood Use Range Hood Control Panel Range Hood Care Clean the Exterior Surfaces Clean or Replace the Baffle Filters...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF FIRE, ELECTRIC low or medium settings. SHOCK OR PERSONAL INJURY, PLEASE • Always turn the hood ON when cooking at READ THE FOLLOWING CAREFULLY BEFORE high heat or when flambeing food (i.e. Crepes ATTEMPTING TO ASSEMBLE, INSTALL, Suzette, Cherries Jubilee, Peppercorn Beef OPERATE OR MAINTAIN THE RANGE HOOD:...
- Page 5 INSTALLATION PREPARATIONS VENTING REQUIREMENTS DO NOT • Have the venting system go vertically from • End the venting system in an enclosed area the range hood to the roof if possible. indoors. • Have 24"-30" distance between the cooktop • Use plastic vent.
- Page 6 INSTALLATION PREPARATIONS IMPORTANT! • If long duct run is needed, increase the duct size from 8" to 9" or 10". • If a reducer is needed, use a long reducer instead of a pancake reducer and install it as far away from the range hood as possible. Reducing the duct size will restrict and decrease the speed of the airflow and hense lower the range hood's performance.
- Page 7 INSTALLATION INSTALLATION INSTRUCTIONS CAUTION CAUTION! Make sure the range hood is securely mounted before releasing. Wear gloves to protect against sharp edge. INSTALLING THE RANGE HOOD • For a more secure installation, install additional screws into the pre-drilled holes on the •...
- Page 8 INSTALLATION INSTALLING THE OIL CONTAINER INSTALLING THE BAFFLE FILTERS • Locate 2 Brackets at the hood bottom, one on • Peel off the protective film from the baffle each side, near the back of the range hood. filters if there's any. •...
- Page 9 RANGE HOOD USE Range Hood Control Panel DELAYED AUTO SHUT-OFF • When the hood is operating in any speed, touch Hand Delayed Hand Gesture Gesture Auto the this button once will activate the Delayed Control Censor Shut Off Light Speed Power Auto Shut Off function.
- Page 10 RANGE HOOD USE The Delayed Auto Shut Off function will turn off • the Light automatically when the timer reaches SPEED (-) (+) • While the range hood is off: Touch the Speed (-) button to turn on the • Range Hood on the highest speed (F4).
- Page 11 RANGE HOOD CARE CLEANING • Pull the spring release handle and push the filter into position. WARNING • Release the handle. • Repeat the steps for the remaining filters. • To reduce the risk of electrical shock, DO NOT REPLACING THE FILTERS clean the hood while it's operating.
- Page 12 RANGE HOOD TROUBLESHOOTING Before Calling for Service Issue Possible Cause / Solution • Check if the range hood is plugged in. Make sure that all power The range hood doesn't turn on is turned ON, the fuse isn't blown and all electrical wirings are properly connected.
- Page 13 • Repair parts or replacement products will be provided by Awoco, free of charge, on an • Contact us at 1-888-412-3428, between 10 exchange basis, and will be either new or AM and 5 PM, Monday - Friday, Pacific Time.
- Page 14 Website: www.awoco.com Customer Support: 1-888-412-3428...
