- Page 1 UGA Kitchen Range Hood S0176 Series INSTRUCTION MANUAL Model No: S0176F1H1 READ AND SAVE THE INSTRUCTIONS For Residential Indoor Use Only...
- Page 2 254mm x 82.5mm (Rear) Dimension (mm) W756 x D562x H180 The data is subjected to change without notice due to product development. Contact your local seller for exchange if defective or damage. Parts and sale, please email: sales@awoco.com More information, please visit: www.awoco.com...
- Page 3 WARNING TO RUDUCE THE RICK OF FIRE, ELECTRIC SHOCK OR INJURY, PLEASE OBSERVE THE FOLLOWINGS: １． Installation work and electric wiring (including switch location) must be done by the qualified person(s) in accordance with local applicable codes and standards, including fire-rated construction. ２．...
- Page 4 WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. Always turn hood ON when cooking at high heat or when flambéing food (i.e.
- Page 5 PART LISTS INSTALLATION & USE NOTE: on the stainless steel range hoods, carefully remove the plastic protective film from exterior of the surfaces of the hood prior to final installation. Caution: To Reduce Risk of Fire and Electric Shock, install this range hood only with integral blowers manufactured by UGA, the model of S0176.
- Page 6 DESCRITION/CONNECTION This appliance should be mounted to the bottom of a standard wall cabinet. If the hood must be mounted directly to the wall, secure the hood to wall studs. Ductwork can be installed vertically or horizontally. Duct runs should be as short as possible. ...
- Page 7 3. Install the ductwork so that it is flush to the range hood’s mounting surface. 4. Run two-conductor wire from a power source to the hood location. Bring approximately 12’’ of wiring through wring hole. 5. Drill 3/32’’diameter pilot holes at points where mounting holes are marked in cabinet bottom.
- Page 8 Install the large shutoff plate on the back of the hood. Using 5 screws. Install the rubber gasket（included） on the top of the hood. As shown below. 6’’ ROUND DUCT INSTALLATION Mount 6’’ round duct on the top of the hood, using 10 screws...
- Page 9 Seal with duct tape. ’ ’×10’ ’ DUCT INSTALLATION 4. Mount 3 ″ × 10 ″ duct on the top of the hood, using 5 screws (included). 5. Seal with duct tape.
- Page 10 HOOD PREPARATION-HORIZONTAL DISCHAREG INSTALLATION ’ ’×10’ ’ DUCT INSTALLATION 1. Install the gasket (included) on the top of the hood, as shown below. 2. Mount the shutoff plate on the top of the hood, using 10 screws (included), 3. Seal with duct tape. 4.
-
Page 11: Hood Installation
HOOD INSTALLATION Insert the power cable in the hood and tighten the wire clamp to screw the cable. Align hood’s keyhole mounting slots over the 4 partially installed screws. Making sure the duct positions over the hood’s duct adapter, push the hood against the rear wall. -
Page 12: Light Bulb
LIGHT BULB This range hood may require two halogen bulbs (Type JCD, 12V, 20W Max, G-4 Base) WARNING: Always switch off the electrical supply before carrying out any operation on the appliance. To change bulbs: Remove the halogen bulb cover ② by using the flat screw driver. Remove the bulb by pulling sideward (DO NOT ROTATE). - Page 13 MAINTENTANCE & CLEAN Disengage the small grease guard cups from the grease guard by turning counterclockwise and remove. Remove the screw retaining the grease guard to the hood. Remove the grease guard from the hood. Then remove the bottom plate. Unscrew the clips and remove the wheel grease collector.
-
Page 14: Wiring Diagram
HOOD CLEANING Stainless steel is one of the easiest material to keep clean. Occasional care will help preserve its fine appearance. Cleaning tips: * Hot water with soap or detergent is usually needed. * Follow all cleaning by rinsing with water. Wipe dry with a clean, soft cloth to avoid water marks.
