Mounting of Turn-type ABSOCODER
Item
5) Shaft mounting position
-Coupling of Turn-type ABSOCODER
Item
1) Coupling device
selection precaution
2) Coupling device
installation precaution
1.
2.
3.
Explanation
Explanation
19
Precaution
Precaution
The selection of a
larger coupling than
necessary will increase
the shaft load which is
caused by the
mounting error amount.
Excessive force applied
to the shaft can deform
the coupling and reduce
durability.
