(3) Input / Output Specification
Items
Input signals
Input circuit
Input logic
Rated input voltage
Input
Rated input current
ON voltage
OFF voltage
Output signals
Output circuit
Output logic
Output
Rated load voltage
Max. load current
Max. voltage drop
when ON
Specifications
HD (Position data HOLD): 1 point
DC input, photo-coupler insulation
Negative logic
24VDC
10mA(24VDC)
10VDC or more
4VDC or less
D0 to D15 (Position data): 16 points
LP (Latch pulse: position data reading timing): 1 point
SE , SE(Sensor disconnected error): 2 points
insulation, photo-coupler open collector output
D0 to D15 , LP , SE :negative logic
SE:positive logic
24VDC(30VDC max.)
D0 to D15 , LP :10mA / point
SE , SE: 100mA / point
0.8V
6
±
10%
