Restricted Sim Usage - Furuno Felcom 30 Operator's Manual

5.7.4

Restricted SIM usage

Allowed SIM
FELCOM 30 can be set to operate from:
Lock SIM, locked to one specific SIM card. Any other SIM user will be
rejected.
No SIM card. All SIM users will be rejected.
Any SIM card.
Setting SIM restrictions
(owner level only)
1 Double-click the Restrict SIM usage icon.
2 The SIM restrictions window shows an example with the setting Allowed
SIM: No SIM.
Click Any (default) to set FELCOM 30 for operation from a specific card only.
Lock SIM:
3 Click Lock and insert the actual SIM card.
FELCOM 30 can now be operated with that specific card only.
4 When retracting the card, the Id of the SIM provider is displayed.
Ok stores the settings.
1
SBS
2
3
4
A l l o w e d S I M :
C a r d n u m b e r :
P l e a s e r e t r a c t t h e S I M c a r d .
5. CONFIGURATION FROM PC
COM1 43C 33C
L o c k e d t o o n e
8 9 0 0 1 2 3 4 5 6 7 8 6 7
5-15
