5. CONFIGURATION FROM PC
5.12

Routing of incoming calls

When applying for IMN numbers, a Terminal Id (OID/DID) is received from the
Net service provider. All devices connected to FELCOM 30 can make outgoing
calls. For incoming calls it must be assured that the Terminal Ids and MSN
numbers configured are as commissioned.
To make an incoming call reach a particular device, an MSN number and the
Terminal Id "connected" to the IMN number must be programmed into the
Communication Unit (CU). See later in this manual.
The table below lists valid MSN numbers for the available ISDN services.
Numbers to be programmed:
In ISDN device:
MSN number
For an easy start, the some Terminal Ids and MSN numbers have been
preprogrammed into the CU (marked with a star in the table).
Note: A Term.Id already entered is not accepted.
ISDN PORTS
4.8 kbps speech
Term.ld MSN
01*
02*
03*
01/20: -first ISDN Handset
03/22 -first ISDN Handset
02/21 -analogue phone on TA
5-26
MSN number and Terminal Id
(the Terminal Id is paired with a specific IMN number)
VALID TERMINAL IDs AND MSN NUMBERS
20*
21*
22*
04 23
05 24
06 25
07 26
08 27
09 28
21/60, preset for RS-232A port
22/61, preset for RS-232B port
23/62, preset for USB port
In Communication Unit:
ISDN/RS-232/USB PORTS
9.6 kbps data
Term.ld MSN
21* 60*
22* 61*
23* 62*
24 63
25 64
26 65
27 66
28 67
29 68
9.6 FAX VIA TA
9.6 kbps fax
Term.ld MSN
11* 40
12 41
13 42
11/40: -fax on TA
