4.8

Telefax service

General
FELCOM30 provides access to Group 3 telefax service via Terminal Adapter.
The transmission rate is 9.6 kbps.
Limitations
FELCOM30 is fully compatible with the world's leading telefax machines and
telefax software standards. However, transmission may not be possible through
some of the telefax machines available on the market. Please check with your
Net service provider/FURUNO Distributor before purchasing a telefax for use
with FELCOM30.
Transmission
Telefax calls made by FELCOM30 are telefax only. Any telephone handset
connected to the telefax machine can not be used.
To send a fax, use the same dialing sequence as when making a call. See "2.12
Various call procedures" earlier in this manual.
Telefax transmissions normally take 1 minute per standard text page using
standard resolution. Using superfine or halftone resolution will double the
transmission time. To save time, avoid using a separate cover page.
If a call failure should occur while sending a multi-page document, re-send only
the failed pages.
Note! On a telefax with keypad, enter
last digit before starting transmission.
ON
48 VDC
SYNC
ALARM
RS-232 B
RS-232 A
5 4 3 2 1 5 4 3 2 1
9 8 7 6 9 8 7 6
FELCOM30 CU
4. OPERATION FROM PC
ISDN
ISDN
USB
ISDN
RS-422
Terminal
Adapter
Analogue
telephone
as the
Analogue
telefax(G3)
4-13
