Starting Up - Furuno Felcom 30 Operator's Manual

4.2

Starting up

Switch ON FELCOM 30. See figure on page 2-2 for location of the ON/OFF
switch.
Turn ON the PC and click Start>Programs>vtLite Mobile.
Note: The vtLite can only be used on one PC at a time.
1 The satellite search program is initialized.
See also "3.2 Satellite search".
2 FELCOM 30 starts searching for last known satellite/elevation (Ocean
Region) as default.
3 When receiving a satellite signal, a signal strength bar will appear in the
search window.
The longer the signal bar or higher the signal strength indicator value, the
better the signal quality. The maximum marker indicates the highest signal
strength achieved during the current search.
Beam was selected. In global beam, "GLB" is shown.
If spot selection is not complete, SBS is shown as above.
S/N ratio
4. OPERATION FROM PC
4-3
